Appendix A – AES/EBU Interface

Inputs with Sample Rate Conversion

The inputs of AES/EBU port A (channels 1 through 8) have sample rate conversion available. These sample rate

converters combine a wide input-to-output sampling ratio with outstanding dynamic range and ultra low distortion,

resulting in high quality even at a 1:1 conversion (where many SRCs offer their lowest quality). In many instances the

converters may be left in-circuit albeit at the expense of increased delay through these inputs. If required, the sample

rate converters can be bypassed, in pairs, as described in the System Settings and Diagnostics section of this guide.

Input Sample Rate and Auxiliary Data

The input sample rate is not extracted from channel status bits but measured from the selected AES/EBU stereo pair

on port A (see page 19). Information about ‘Legacy’ or ‘High Speed’ mode may be extracted from the channel status

bits if the in-coming stream contains this information but this should not be relied upon (see pages 14 through 17).

Inputs without Sample Rate Conversion

The inputs of AES/EBU ports B and C (channels 9 through 24) do not have sample rate converters. Any signals applied

to these inputs (and port A if the sample rate converters are bypassed) must be synchronized to the system.

Output Auxiliary Data

The following will be set in the auxillary data fields of all AES/EBU output streams:

Channel Status Data Indication of the selected sample rate and mode (‘Legacy’ or ‘High Speed’)

All other channel status fields default to ‘1’

User Data Bit Always set low (‘0’)

Validity bit Always set true (valid)

Parity Bit Always recalculated
