Replacement Parts and Accessories
Furnished Accessories
Microphone Stand Adapter (UR2)
WA371
Threaded locking Adapter (with TA4F), UR1
WA340
Zipper Bag (UR1)
26A13
Zipper Bag (UR2)
26A14
Antenna Extension Cables (2)
95B9023
RF Distribution Cables (2)
95N2035
Antenna (UR1, UR1M) 470-530 MHz
UA700
Antenna (UR1, UR1M) 518-578 MHz
UA710
Antenna (UR1, UR1M) 578-698 MHz
UA720
Antenna (UR1, UR1M) 740-865 MHz
UA730
Antenna (UR1, UR1M) 944-952 MHz
UA740
Two Antennas (UR4+), Band Dependent (see table)
UA820
Transmitter Carrying Case
95C9053
Optional Accessories
SM58 Head with Grille
RPW112
SM86 Head with Grille
RPW114
BETA 58 Head with Grille
RPW118
BETA 87A Head with Grille
RPW120
BETA 87C Head with Grille
RPW122
SM87A Head with Grille
RPW116
KSM9/SL Head with Grille
RPW180
KSM9HS Head with Grille (Champagne, Condenser)
RPW182
KSM9/BK Head with Grille
RPW184
KSM9HS Head with Grille (Black, Condenser)
RPW186
Matte Silver Grille (SM58)
RK143G
Matte Silver Grille (SM86)
RPM266
Matte Silver Grille (BETA 58)
RK265G
Black Grille (SM87)
RK214G
Matte Silver Grille (BETA 87A)
RK312
Matte Silver Grille (BETA 87C)
RK312
Black Grille (BETA 58)
RK323G
Black Grille (BETA 87A/BETA 87C)
RK324G
Champagne Grille (KSM9/SL)
RPM260
Black Grille (KSM9/BK)
RPM264
Popper Stopper‘ Windscreen
A85WS
Belt Clip (UR1)
44A8031
Bodypack Pouch (Black), UR1
WA580B
Bodypack Pouch (White), UR1
WA580W
Bodypack Pouch (Black), UR1M
WA581B
Bodypack Pouch (White), UR1M
WA581W
3-Pin mini Lemo conversion kit, UR1M
WA335
Antenna Combiners and Accessories
• Antennas and receivers must be from the same frequency band.
• The supplied 1/2 wave antennas can be remotely mounted or
mounted directly to the UA845.
• Antennas and cables for use with the UA845 can also be used
with stand-alone UHF-R receivers.
Passive Antenna/Splitter Combiner Kit
(recommended for 2 receivers)
UA221
UHF Antenna Power Distribution Amplifier
UA845-
U.S.A. (470-952 MHz)
UA845SWB
Europe
UA845E
UK
UA845UK
1/2 Wave, Omnidirectional,
Wideband Antenna (470-952 MHz)
UA860SWB
Active Directional Wideband Antenna
(470-698 MHz)
UA870USTV
Active Directional Narrowband Antenna
(944-952 MHz)
UA870X
Wideband In-Line RF Amplifier (470-698 MHz)
UA830USTV
Narrowband In-Line RF Amplifier (944-952 MHz) UA830X
Passive Unidirectional Wideband Antenna
(470-952 MHz)
PA805SWB
Passive Unidirectional Narrow band Antenna
(944-952 MHz)
PA805X
1/2 wave antennas (2)
G1 Band
UA820G
H4E, H4 Bands
UA820H4
J5E, J5 Bands
UA820J
L3E, L3 Bands
UA820L3
Q5, Q6, Q10A Bands
UA820Q
R9, ABJ Bands
UA820A
X1 Band
UA820X
10’ Antenna Cable
PA725
25’ Antenna Cable (RG-8/X)
UA825
50’ Antenna Cable (RG-8/X)
UA850
100’ Antenna Cable
UA8100
Architects' and Engineers' Specifications
The wireless system shall operate in the UHF band between 470-865 MHz and 944-952 MHz, with the specific range being dependent on the user's
locale. The system shall include the option of changing the operating frequency in order to avoid RF interference, enabling up to 160 systems to operate
simultaneously in the same location. Preconfigured group, channel and frequency setups shall be available to ensure that multiple systems in use do not
interfere with one another.
All transmitters shall be powered by 2 AA batteries and shall have a power on/off switch. The bodypack will have an LED indicating that power is on.
Available transmitters shall include: a body pack for use with electric guitars, basses, and other electric instruments, and a handheld microphone for
vocals. The transmitters shall have a DC/DC converter to ensure consistent performance, even if battery voltages change.
The receiver shall have a user-programmable, menu-driven LCD showing group, channel, frequency, name, squelch level, and locked/unlocked status.
The system shall use technology such as MARCAD‚ signal combining circuitry to improve reception, minimize signal dropouts, and achieve the best
possible signal-to-noise ratio. An equalizer, tone key squelch, and noise squelch circuitry shall be built into the system to provide optimal sound quality
and minimize unwanted noise. The receiver shall include dual RF meters (one for each antenna), an audio level meter, and a Networking Interface
connector for computer control and monitoring. The receiver shall have a volume control and an adjustable noise squelch control.
The system shall be the Shure UHF-R Wireless.
