J5E FREQUENCY BAND (578.000 - 638.000 MHz)
Channel
Full Range
max. #
of comp.
frequencies
(option 1)
Full Range
max. #
of comp.
frequencies
(option 2)
France
preferred:
User Group
A
(option 1)
France
preferred:
User Group
A
(option 2)
France
preferred:
User Group
B
(option 1)
France
preferred:
User Group
B
(option 2)
France
preferred:
User Group
C
(option 1)
France
preferred:
User Group
C
(option 2)
All Bands All Bands
Group 1 Group 2 Group 3 Group 4 Group 5 Group 6 Group 7 Group 8 Group 9 Group 10
1 578.375 578.375 578.500 578.500 578.225 578.225 578.775 580.000 589.375 581.050
2 579.400 579.100 579.250 579.250 578.975 578.975 580.000 580.700 590.525 582.400
3 581.750 580.175 579.750 582.750 580.900 580.900 582.300 581.100 591.175 583.950
4 582.625 583.125 583.250 583.250 582.500 581.300 583.000 581 900 595.300 584.950
5 584.675 583.625 585.750 585.750 585.500 582.500 584.975 584 975 596.350 585.700
6 587.350 584.825 587.500 591.750 593.500 586.975 589.100 591.000 600.375 589.250
7 588.825 585.800 593.250 593.250 594.975 592.025 592.225 594.775 601.875 589.900
8 589.225 587.350 595.500
595.500 597.300 598.500 597.100 597 500 602.825 591.125
9 594.200 593.475 598.750 604.250 604.900 606.100 597.900 605 900 604.925 593.350
10 594.725 595.400 610.500 607.500 605.700 608.775 605.500 606.300 605.700 599.100
11 596.975 596.750 611.250 608.500 606.100 609.500 608.975 608 225 616.900 610.300
12 603.475 599.800 615.500 609.250 610.975 610.975 610.775 610.775 622.650 611.075
13 606.050 608.275 623.250 617.750 624.775 620.900 621.500 621.100 624.875 613.175
14 607.725 609.950 623.750 623.250 626.975 624.775 623.000 624 975 626.100 614.125
15 616.200 612.525 625.750 623.750 628.900 628.900 628.000 626.775 626.750 615.625
16 619.250 619.025 631.750 625.750 630.500 630.500 628.700 631.000 630.300 619.650
17 620.600 621.275 633.250 633.250 636.500 634.225 634.775 634.025 631.050 620.700
18 622.525 621.800 634.500 634.500 636.900 634.975 636.700 634.775 632.050 624.825
20 630.200 627.175 636.250 636.250 580.500 637.700 637.900 637 500 634.950 626.625
21 631.175 628.650 583.750 580.250 584.775
586.225 578.025 584 225 594.000 586.250
22 632.375 631.325 585.250 587.750 596.900 588.500 594.025 596.000 620.625 595.375
23 632.875 633.375 599.500 590.750 598.100 589.300 594.775 598.300 629.750 622.000
24 635.825 634.250 600.500 594.500 598.500 600.025 596.700 605.100 579.850 593.850
25 636.900 636.600 601.750 599.750 600.775 604.500 606.300 608 975 580.950 607.800
26 637.625 637.625 602.500 601.750 610.225 605.700 610.025 620.700 586.800 629.200
27 581.200 581.775 603.750 602.500 616.775 614.100 621.900 621 900 608.200 635.050
28 586.450 592.150 606.750 603.500 621.700 621.700 626.775 622.300 622.150 636.150
29 592.725 594.275 608.500 611.250 626.225 626.225 630.300 624 225 598.250 581.900
30 597.900 595.825 609.250 615.500 630.100 626.975 631.000 630.300 606.250 598.100
31 598.600 598.850 612.250 619.250 634.225 630.100 611.900 603.050
32 604.000 600.400 619.500 620.250 634.975 636.500 612.950 604.100
33 605.350 601.550 620.250 625.250 617.900 609.750
34 614.450 610.650 625.250 626.500
634.100 617.750
35 615.600 612.000 626.500 631.500
36 617.150 617.400 633.750 632.500
37 620.175 618.100
38 621.725 623.275
39 623.850 629.550
40 634.225 634.800
