M5E FREQUENCY BAND (694–758 MHz)
Channel
Group 1 Group 2 Group 3 Group 4 Group 5 Group 6 Group 7 Group 8 Group 9 Group 10
Full Range
max. # of
compatible
frequencies
694 - 758 MHz
(option 1)
Full Range
max. # of
compatible
frequencies
694 - 758 MHz
(option 2)
Full Range
max. # of
compatible
frequencies
694 - 758 MHz
(option 3)
Full Range
max. # of
compatible
frequencies
694 - 758 MHz
(option 4)
France
preferred:
User Group A
694 - 758 MHz
(option 1)
France
preferred:
User Group A
694 - 758 MHz
(option 2)
France
preferred:
User Group A
694 - 758 MHz
(option 3)
France
preferred:
User Group B
694 - 758 MHz
(option 1)
France
preferred:
User Group B
694 - 758 MHz
(option 2)
France
preferred:
User Group B
694 - 758 MHz
(option 3)
1 694.400 694.950 698.025 694.350 694.750 697.250 695.500 696.025 697.500 696.025
2 695.175 696.000 699.375 695.075 699.250 698.500 702.750 696.775 701.700 698 225
3 696.400 698.625 701.125 695.550 704.500 699.500 704.500 698.225 702.500 700 900
4 696.925 700.825 702.225 696.575 707.250 708.250 707.750 705.500 706.975 705 500
5 699.025 702.775 703.075 700.275 715.500 713.250 716.250 720.025 722.975 708 500
6 700.550 703.575 705.450 701.675 716.250 719.500 721.750 722.975 724.500 708 900
7 703.425 707.375
707.575 703.800 722.500 727.500 722.500 725.300 734.500 714 225
8 704.500 708.825 714.625 707.025 728.500 735.250 723.750 732.900 738.225 718.100
9 708.225 710.900 718.650 708.700 735.750 737.750 739.500 738.975 740.900 729 500
10 711.375 717.350 720.500 709.600 737.250 739.250 743.750 740.900 746.975 734 500
11 715.625 719.200 721.175 711.625 747.750 739.750 746.500 742.100 748.900 736.025
12 717.050 720.400 722.150 715.050 750.750 744.500 747.500 745.500 749.300 740 500
13 727.050 720.750 729.925 729.275 751.250 745.250 753.250 750.500 752.775 754 975
14 730.500 722.050 735.550 733.100 753.250 748.250 755.750 757.300 698.225 757.300
15 731.125 734.725 735.925 734.425 754.500 751.750 756.250 701.300 700.500 697 500
16 740.875 739.825 740.700 734.900 755.500 694.750 694.750 702.500 701.300 709.700
17 741.750 740.875 744.850 741.675 695.500 695.500 696.500 704.775 704.025 716 500
18 746.675 745.375 747.850 744.600 696.500 696.500 699.500 710.500 708.900 728.775
19 748.725 748.525 751.700 746.075
698.500 697.750 711.500 712.025 709.300 734.100
20 749.150 751.875 752.425 747.025 700.250 700.250 713.750 716.500 710.100 738 975
21 750.375 752.650 753.375 748.225 702.750 706.500 714.500 716.900 712.025 741.300
22 753.550 753.900 753.950 750.950 703.500 707.750 715.500 718.100 730.225 741.700
23 755.400 754.250 754.800 751.575 711.250 711.250 720.500 726.100 733.300 744.025
24 755.925 755.650 755.275 753.475 719.500 713.750 727.750 730.225 733.700 749.700
25 756.900 757.850 757.425 755.100 720.500 715.500 732.250 733.300 740.500 754 225
26 699.625 695.325 694.275 697.000 721.750 722.500 740.250 736.025 742.500 756 900
27 714.775 699.975 695.300 697.825 730.500 728.500 743.250 746.975 750.100
28 717.775 726.375 695.975 713.975 731.500 730.500 745.250 753.500 754.225
29 721.050 735.600 706.025 722.450 739.500 732.250 745.750 754.225 754.975
30 728.550 740.225 709.375 730.425 740.250 734.750 751.500 756.900
31 743.650 743.475 730.825 737.900 742.750 742.750 752.500
32 747.450 746.550 755.950
756.525 747.250 747.500 753.750
33 698.175 697.800 697.100 699.250 756.250 752.500
34 702.675 705.175 704.700 699.850
35 705.300 706.525 715.375 707.975
36 707.525 709.775 716.300 716.500
37 713.275 713.375 723.450 717.300
38 718.825 713.725 726.775 717.750
39 720.300 718.425 727.425 720.200
40 725.275 722.575 729.400 721.825
41 727.525 725.250 733.275 727.950
42 732.175 728.925 733.950 728.950
43 734.550 734.075 736.900 732.225
44 735.475 736.000 741.500 733.675
45 736.625 737.625 742.650 749.200
46 740.225 742.450 743.500 753.125
47 754.325 743.825 746.775 754.475
48 756.275 756.375 750.275 757.550
