User's Guide HDSPe MADI FX © RME

Preset. Settings of the EQ and the Low Cut

can be stored, loaded, and copied between

channels at any time. A click on Preset opens

a menu with several entries:

¾ Recall: Presets stored before by the user

can be selected and loaded

¾ Save to: There are 16 storage places

available (EQ Preset 1 to 16)

¾ Import: Loads a previously stored TM EQ

file (.tmeq)

¾ Export: Stores the current state as TM

EQ file (.tmeq)

¾ Factory: Includes 14 examples for the

creative use of Low Cut and Equalizer

¾ Reset: Resets the Low Cut and EQ to

have zero influence (Gain 0 dB)

¾ Rename: The EQ Presets 1 to 16 can be renamed. The changes will be shown in both lists

Recall and Save to.

Notes on the EQ Presets

Copy between channels: The EQ Preset menu of all channels is identical. If an EQ setup is

stored via Save to on one of the 16 storage places, it is then also available in any other channel

via Recall.

Copy between Snapshots: The Presets are not saved in Snapshots, therefore do not change

when a different Snapshot is loaded. Presets are saved in Workspaces and also loaded with

these.

Copy between Workspaces: is done by the export and import function of the Preset menu.

Important and useful Presets should always be saved as TM EQ file, so that they can not get

lost even on accidental overwrite.

Factory Presets: loaded like all Presets the settings of both Low Cut and EQ simultaneously.

The current state, On or Off, is neither saved nor activated on load. With this a preset can be

loaded anytime, but will not become active before the user decides to switch the EQ and/or LC

on – except they had been active already before the load process. For this reason some Fac-

tory Presets have special names. For example Telephone (LC+EQ) will sound much better

when the LC has been activated additionally to the EQ, as the LC is set to an unusual high fre-

quency of 500 Hz here.
