25.5.4 Scroll Location Markers

Another feature to improve overview and working with TotalMix FX are scroll location markers

(TotalMix view only). These are displayed automatically when the horizontal size of the TotalMix

FX window is smaller than the channel display requires. Shown on the right side of the scrollbar

of each row they have four elements:

¾ Arrow to the left. A left mouse

click let the channels scroll to the

very first one, or most left.

¾ 1. Marker number 1. Scroll to the

desired position and perform a

right mouse click on 1. A dialog

comes up with precise

information. Once stored, a left

mouse click will scroll the

channels to the stored position.

¾ 2. Marker number 2. See 1 for

details.

¾ Arrow to the right. A left mouse

click let the channels scroll the

last one, or most right.

Scroll location markers are stored in

the Workspace.

Application Examples

• When the TotalMix FX window is intentionally made small in width, so only a few channels

are shown.

• When the available screenspace is not sufficient to show all channels.

• When some or all EQ or Dynamics panels are open. Then all relevant settings are always

visible, but require a lot of space horizontally.
