Soundcraft Si Performer 2 [123/135] Add edit user

User Manual

11.3.1: ADD / EDIT USER

SYSTEM SETTINGS > SECURITY > ADD / EDIT USER

11.3.1: SYSTEM SETTINGS > SECURITY > ADD / EDIT USER

CANCEL

Cancel the current User creation or edit without saving any altered values.

SAVE

Save the current User.
