User's Guide ADI-648 © RME
11
6.4 Outputs ADAT Optical
The ADI-648 provides 8 outputs in ADAT optical format. They are fully compatible to all ADAT
optical inputs. A usual TOSLINK cable is sufficient for connection.
With the Matrix Router de-activated, all MADI channels are copied to the 8-channel ADAT for-
mat in a logical order:
MADI In 1-8 9-16 17-24 25-32 33-40 41-48 49-56 57-64
ADAT Out 1 2 3 4 5 6 7 8
If a MADI signal in Double Wire format (standard frame) is present at the input, technically no
special processing is activated, because the output signals will be in Sample Split format
(S/MUX) right away.
In 96K FRAME mode, the ADI-648 automatically converts Double Speed data to Sample Split
(S/MUX). The data of one MADI channel will be processed and routed to two ADAT channels
according to the following table:
MADI In 1 2 3 4 5 6 7 8
DS Signal
Port
1/2
1
3/4
1
5/6
1
7/8
1
1/2
2
3/4
2
5/6
2
7/8
2
MADI In 9 10 11 12 13 14 15 16
DS Signal
Port
1/2
3
3/4
3
5/6
3
7/8
3
1/2
4
3/4
4
5/6
4
7/8
4
MADI In 17 18 19 20 21 22 23 24
DS Signal
Port
1/2
5
3/4
5
5/6
5
7/8
5
1/2
6
3/4
6
5/6
6
7/8
6
MADI In 25 26 27 28 29 30 31 32
DS Signal
Port
1/2
7
3/4
7
5/6
7
7/8
7
1/2
8
3/4
8
5/6
8
7/8
8
As the device internally always operates in Sample Split mode, the Matrix won't change its func-
tionality in Double Wire, Quad Wire (Sample Split = Single Speed) and 96K Frame (Double
Speed). In both cases the number of channels is reduced to 28/32 or 14/16. At the same time
the Matrix Router no longer operates in 8-channel, but in 4-channel or 2-channel blocks.
