User's Guide ADI-648 © RME
29
Table 1
No. Name
Request
Value
Set
Value
Value
Response
Data bytes
00h MADI input select x x x 1 Byte, 0 = BNC, 1 = optical
01h MADI input state x x
1 Byte, 0 = normal operation,
1 = Redundancy mode
02h MADI sync state x x 1 Byte, 0 = error, 1 = lock, 2 = sync
03h MADI audio state x x 1 Byte, see table 2
04h MADI audio state x x 1 Byte, see table 2
05h
MADI input format
display
x x
1 Byte, bit 0: 0 = 56ch / 1 = 64ch,
bit 1: 0 = 48k frame, 1 = 96k frame
06h WCK input state x x 1 Byte, 0 = no lock, 1 = lock
10h ADAT in 1 and 2 state x x 1 Byte, see table 3
11h ADAT in 3 and 4 state x x 1 Byte, see table 3
12h ADAT in 5 and 6 state x x 1 Byte, see table 3
13h ADAT in 7 and 8 state x x 1 Byte, see table 3
14h ADAT audio state x x 1 Byte, see table 2
15h ADAT audio state x x 1 Byte, see table 2
16h 96k frame x x x 1 Byte, bit 0: MADI on, bit 1: WCK on
20h clock source x x x
1 Byte, 1 = INT 44, 2 = INT 48,
3 = WCK, 4 = MADI, 5 = ADAT
30h matrix enable x x x 1 Byte, 0 = disable, 1 = enable
31h matrix reset x 1 Byte, 1 = reset
40h matrix output 1 x x x 1 Byte, 0..15 = input no., 16 = no input
41h matrix output 2 x x x 1 Byte, 0..15 = input no., 16 = no input
42h matrix output 3 x x x 1 Byte, 0..15 = input no., 16 = no input
43h matrix output 4 x x x 1 Byte, 0..15 = input no., 16 = no input
44h matrix output 5 x x x 1 Byte, 0..15 = input no., 16 = no input
45h matrix output 6 x x x 1 Byte, 0..15 = input no., 16 = no input
46h matrix output 7 x x x 1 Byte, 0..15 = input no., 16 = no input
47h matrix output 8 x x x 1 Byte, 0..15 = input no., 16 = no input
48h matrix output 9 x x x 1 Byte, 0..15 = input no., 16 = no input
49h matrix output 10 x x x 1 Byte, 0..15 = input no., 16 = no input
4Ah matrix output 11 x x x 1 Byte, 0..15 = input no., 16 = no input
4Bh matrix output 12 x x x 1 Byte, 0..15 = input no., 16 = no input
4Ch matrix output 13 x x x 1 Byte, 0..15 = input no., 16 = no input
4Dh matrix output 14 x x x 1 Byte, 0..15 = input no., 16 = no input
4Eh matrix output 15 x x x 1 Byte, 0..15 = input no., 16 = no input
4Fh matrix output 16 x x x 1 Byte, 0..15 = input no., 16 = no input
60h device ID x x x 1 Byte (00h..7Eh, 7Fh = broadcast)
