RACK ADAPTERS INCLUDED

Unscrew the 4 anchor

points of the front panels

and remove it.

F i x b y t h e

supplied screws

t h e t w o r a c k

a d a p t e r s a s

s h o w n i n t h e

Remove the smaller steel

spacer (S2) from DEVICE A

and traslate S1 on DEVICE

B like in the draw beside.

Then refit the front panels

fixing all the 4 screws on

DEVICE B and just the two

ones through S1 on the

Plug the two

d e v i c e s

the last two

fix the rack
