P. 6

USER'S MANUAL

9. REMOTE CONTROL SOFTWARE

1 . To connect the K-array modules to a PC, it is needed a RS485-USB adapter, we recommend the K-USB adapter (pic.1).

2 . Install the K array control software from installer in the CD-ROM

2.1 Start the Karray_manager_V2 from Windows - Start - Software - Karray_manager_V2

2.2 Click on NO when ask for demo mode start

2.3 Click on System - Settings to configure which COM port use, the COM port of K-USB, usually is the higher number.

If you don't find, you can check it on windows-control panel-system-hardware-COM Port

Connect the K-usb to a PC and install the drivers required included in the CD-ROM.

K-USB

USB to RS485 adapter

Operating systems:

Win98/98SE/Me/2000/XP/Vista

Minimum requirements:

CPU 300 MHz

RAM 128 Mb

Recommended requirements:

RAM 512 Mb

SYSTEM REQUIREMENTS
