18
AUTOMATIC MODE
Automatic demo game without
DMX controller
ChPr
Chase with 16 steps
previously created in REC
MODE
Speed and Wait time
selectable by user
CUPr
RGB values selectable by
user
Rainbow (rAIn)
Rainbow colours effect.
Speed time selectable by user
CU01-CU16
Color Macros as on DMX
channel 8 (Macro)
WHITE MACROS
16 macros for White color
from 2800 to 6500 ° K
DIMMER
Dimmer level selectable by
user as on DMX channel 2
(Dimmer)
Dimmer level is active for all
the programs and macros
SHUTTER
Shutter level selectable by
user as on DMX channel 1
(Shutter)
Shutter level is active only for
CU01/CU16 and Wh01/Wh16
macros
ESC
Esc from Automatic Mode
Menu
