JBL CONTROL 24СТ [4/19] Product feature identification
![JBL CONTROL 24СТ [4/19] Product feature identification](/views2/2008107/page4/bg4.png)
3
Product Feature Identification
Attachment Screws
Tap Selector (on T-versions)
Loudspeaker
Di
Seismic Tab
(secondary support point)
Perforated Press
-
In Grille
Steel Backcan
Rotating Mounting Tabs
JBL Logo
Removable Lockin
g
In
p
ut Connector
Strain Relief Fitting
Terminal Cover Plate Assembly
(
Control 24C Shown)
