S a f e t y W a r n i n g s
1. Read instructions – all the safety and operating instructions should be read
before the appliance is operated.
2. Retain these instructions – the safety and operating instructions should be
retained for future reference.
3. Heed warnings – all warnings on the appliance and in the operating
instructions should be adhered to.
4. Follow instructions – all operating and other instructions should be
followed.
7. Heat – the appliance should be situated away from heat sources such as
radiators, stoves or other appliances that produce heat.
9. Power cord protection – power supply cords should be routed so that they
are not likely to be walked on or pinched by items placed upon or against
them, paying particular attention to cords at plugs, convenience
receptacles and the point where they exit the appliance.
10. Cleaning – the appliance should be cleaned only as recommended by the
manufacturer.
11. Unattended periods – the power cord of the appliance should be
unplugged from the outlet when left unused for a long period of time.
12. Object entry – care should be taken so that objects do not fall into the
appliance.
13. Damage requiring service – the appliance should be serviced by qualified
service personnel when:
i. the power supply cord or the plug has been damaged
ii. objects have fallen or liquid has been spilled into the appliance
iii. the appliance has been exposed to rain or other serious liquid exposure
iv. the appliance does not appear to operate normally or exhibits a marked
change in performance
v. the appliance has been dropped or the cabinet damaged
14. Servicing – the user should not attempt to service the appliance beyond
those measures described in the operating instructions.All other servicing
should be referred to qualified service personnel.
15. Grounding or polarisation – precautions should be taken so that grounding
or polarisation means for the appliance are not defeated.
5. Water and moisture - the appliance should not be exposed to dripping or
splashing and no objects such as vases, should be placed on the appliance.
6. Ventilation - a minimum 0f 80mm is required at the rear of the appliance
to ensure sufficient ventilation.The ventilation should not be impeded by
covering the appliance with items such as table-cloths, curtains etc. Further,
the appliance should not be built into an installation, such as a bookcase or
cabinet, that may impede the flow or air around the appliance.
8. Power sources - The appliance is of Class1 construction and shall be
connected to a MAINS socket outlet with a protective earthing connection
16. The Mains disconnection switch is located on the rear panel. Pressing the
switch downwards will turn the unit on.The unit can be turned off by upward
pressure on the switch. Please allow enough room around the unit to ensure
the switch is readily operable when the unit is in use.
SCM 50/100/ 15025/45/ 110/
