10 PRO MIXER DJX900USB User Manual
13. Specications
Audio Inputs
Mic +40 dB gain, balanced XLR
Phono in +40 dB gain, unbalanced
Line in 0 dB gain, unbalanced
CD in 0 dB gain, unbalanced
Return 0 dB gain, unbalanced
Audio Outputs
Master Max. +21 dBu
Booth Max. +21 dBu
Tape 0 dBu
Send 0 dBu
Phones out Max. 180 mW @ 75 Ω / 1% THD
Equalizer
Stereo low +8 dB / -27 dB @ 50 Hz
Stereo mid +6 dB / -23 dB @ 1.2 kHz
Stereo high +9 dB / -15 dB @ 10 kHz
Mic low +15 / -15 dB @ 80 Hz
Mic mid +15 / -15 dB @ 2.5 kHz
Mic high +15 / -15 dB @ 12 kHz
Kill low -54 dB @ 50 Hz
Kill mid -43 dB @ 1 kHz
Kill high -25 dB @ 10 kHz
USB
Audio Stereo In / Out
Connector Type B
Sample rate 48 kHz
Digital Eects Processor
DSP Freescale
A/D-D/A converter 24-bit Delta-Sigma,
64/128-times oversampling
Sampling rate 46.875 kHz
System Specication
Signal-to-noise ratio >80 dB (line)
Crosstalk >70 dB (line)
Distortion (THD) <0.03%
Frequency response 10 Hz - 40 kHz, +0/-3 dB
Power Supply
Power consumption 32 W
Mains connection Standard IEC receptacle
Mains Voltages
Europe/UK/Australia/ 220-230 V~, 50/60 Hz
Korea/China
UL 120 V~, 60 Hz
JP 100 V~, 50/60 Hz
Fuse
100-120 V~ T1AH 250V
220-230 V~ T500mAH 250V
Physical
Dimensions (H x W x D) 4.2 x 12.6 x 14.6" / 107 x 320 x 370 mm
Weight 8.2 lbs / 3.7 kg
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts,
modifications may be made from time to time to existing products without prior notice. Specifications and
appearance may differ from those listed or illustrated.
