©American DJ® - www.americandj.com - Reex Pulse LED™ Instruction Manual Page 7
Model: Reflex Pulse LED™
Voltage*: 115v~60Hz / 230v~50Hz
LEDS: 32 Red, 30 Green, 30 Blue, &
45 White (Strobe)
Power Consumption: 27W
Beam Angle: 28 Degrees (Strobe 23 Degrees)
Fuse: 2 Amp
Dimensions: 14.5” L x 12.75” W x 4.5” H
Colors: RGBW
Weight: 12 Lbs./5.5 Kgs.
Warranty: 3 Year (1095 Days)
* Voltage is user selectable.
Please Note: Specications and improvements in the design
of this unit and this manual are subject to change without any
prior written notice.
Reflex Pulse LED™ Specifications
American DJ®
American DJ World Headquarters:
6122 S. Eastern Ave. Los Angeles, CA 90040 USA
Tel: 323-582-2650 / Fax: 323-725-6100
Web: www.americandj.com / E-mail: info@americandj.com
