Operating Modes:
• Sound-Active mode - The unit will react to sound.
• Preset Program - The fixture will run a preset program.
• DMX control mode - This function will allow you to control each
individual fixtures traits with a standard DMX 512 controller such as
as the Elation® Show Designer™.
Test Mode (Preset Program):
Stand-Alone Operation: This function will run the fixture’s preset
program. Note: Sound Active mode must be OFF, to run the preset
program.
1. Press the ESCAPE (ESC) button to get to the main menu. Then
press the UP button until “TEST” is displayed and press ENTER.
2. “MODE 1” will now be displayed, press ENTER.
3. The xture will now run the preset program.
4. The optional UC3 Controller (not included) may be used to control
different functions including blackout.
Sound Active Mode:
Stand-Alone Operation: This mode allows a single unit to run to the
beat of the music.
1. Press the ESCAPE (ESC) button to get to the main menu. Then
press the UP button until “AUDI” is displayed. Press the ENTER
button.
2. Press the UP button to display “ON”. Press ENTER to conrm.
Sound Active mode will start working after 10 seconds.
3. You can adjust the audio sensitivity of the unit by turning the audio
sensitivity knob clockwise located in the rear.
4. The optional UC3 Controller (not included) may be used to control
different functions including blackout.
Master-Slave Operation: This mode will allow you to link up to 16
units together and operate without a controller. In Master-Slave mode,
the units will react to sound. In Master-Slave operation one unit will act
as the controlling unit and the others will react to the controlling units
programs. Any unit can act as a Master or as a Slave.
1. Using standard XLR microphone cables, daisy chain your units
together via the XLR connector on the rear of the units. Remem-
ber the Male XLR connector is the input and the Female XLR
Mystic LED™ Operating Instructions
MAIN MENU -
A.001 - DMX Address Setting
1. Press the ESCAPE button to get to the main menu. Press the
UP button until “A001” is displayed and press ENTER.
2. Tap the UP or DOWN buttons until the address that you want
is displayed and press ENTER.
TEST - This function will activate the preset program. To run
the preset program Sound Active mode must be OFF.
1. Press the ESCAPE (ESC) button to get to the main menu.
Press the UP button until “TEST” is displayed and press EN-
TER. “MODE 1” will be displayed, press ENTER again to acti-
vate the preset program.
AUDI - This function is the Sound Active mode.
1. Press the ESCAPE (ESC) button to get to the main menu.
Press the UP button until “AUDI” is displayed and press EN-
TER.
2. Press the UP button to display “ON” and press ENTER to con-
rm.
3. You can adjust the audio sensitivity of the unit by turning the
audio sensitivity knob clockwise located at the rear of the x-
ture.
Note: When the unit is in Sound Active mode, “test run” will
continuously ash on the LCD screen.
RSET - When you activate the reset function, the xture will
begin the reset motion.
1. Press the ESCAPE (ESC) to get to the main menu. Then
press the UP button until “RSET” is displayed. Press the EN-
TER button to reset the xture.
Mystic LED™ System Menu
©American DJ Supply® - www.americandj.com - Mystic LED™ User Manual Page 8©American DJ Supply® - www.americandj.com - Mystic LED™ User Manual Page 7
