©American DJ Supply® - www.americandj.com - Mystic LED™ User Manual Page 10©American DJ Supply® - www.americandj.com - Mystic LED™ User Manual Page 9
connector is the output. For longer cable runs we suggest a
terminator at the last fixture. Note: You can also daisy chain the
power cords, this can only be done with 20 xtures. After 20
you will need to use a new power outlet. They must be the
same xtures. DO NOT mix xtures.
You do not have to assign the units Master/Slave. They will auto-
matically fall into Master/Slave mode.
2. Use the sensitivity knob on the rear of the master unit to make it
more or less sensative to sound..
3. The optional UC3 Controller (not included) may be used to
control different functions including blackout.
DMX Mode:
Operating through a DMX controller give the user the freedom to cre-
ate their own programs tailored to their own individual needs.
1. This function will allow you to control each individual fixture’s
traits with a standard Elation® DMX 512 controller.
2. The Mystic LED™ uses four DMX channels to operate see page 8
for the DMX traits.
3. To control your fixture in DMX mode, follow the set-up procedures
on pages 5-6 as well as the set-up specifications that are
included with your DMX controller.
4. Follow the instructions on page 7 to set the DMX address.
5. Use the controller’s faders to control the various DMX fixture traits.
Mystic LED™ Operating Instructions
Locate and remove the unit’s power cord. Once the cord has been
removed located the fuse holder located inside the power socket.
Insert a flat-head screw driver into the power socket and gently pry out
the fuse holder. Remove the bad fuse and replace with a new one. The
fuse holder has a built-in socket for a spare fuse be sure not to confuse
the spare fuse with active fuse.
Mystic LED™ Fuse Replacement
Mystic LED™ DMX Traits
Channel Value Function
1 LED OFF/ON & STROBE
0 - 1 LED OFF
2 - 127 STROBE SLOW - FAST
128 - 135 LED ON
136 - 253 RANDOM STROBE SLOW - FAST
254 - 255 LED ON
2 LED COLORS & RAINBOW EFFECT
SPEED CONTROL
0 - 41 RED
42 - 83 RED & GREEN
84 - 125 GREEN
126 - 167 GREEN & BLUE
168 - 209 BLUE
210 - 251 BLUE & RED
252 - 255 ALL ON
0 - 255 RAINBOW EFFECT SLOW - FAST
3 RAINBOW EFFECT
0 - 63 RAINBOW EFFECT OFF
64 - 127 RAINBOW EFFECT ON
128 - 255 RAINBOW EFFECT OFF
4 LED ROTATION
0 NO ROTATION
1 - 85 CLOCKWISE ROTATION FAST - SLOW
86 - 170 COUNTER CLOCKWISE ROTATION
SLOW - FAST
171 - 178 NO ROTATION
179 - 255 RANDOM ROTATION SLOW - FAST
Note: When the Rainbow effect is active (Channel 3, values
64 -127), Channel 2 will control the speed of the Rainbow
Effect (values 0-255).
