User Instructions
LED Pixel 4C Introduction
ADJ Products, LLC - www.adj.com - LED Pixel 4C User Manual Page 2
Unpacking: Thank you for purchasing the LED Pixel 4C by ADJ Prod-
ucts, LLC. Every LED Pixel 4C has been thoroughly tested and has
been shipped in perfect operating condition. Carefully check the ship-
ping carton for damage that may have occurred during shipping. If the
carton appears to be damaged, carefully inspect your xture for any
damage and be sure all accessories necessary to operate the unit has
arrived intact. In the case damage has been found or parts are miss-
ing, please contact our toll free customer support number for further
instructions. Do not return this unit to your dealer without rst contact-
ing customer support.
Introduction: The ADJ LED Pixel 4C is a 4-Channel Driver/Controller
for the LED Pixel Tube 360 (not included). This xture can be used in a
stand alone mode or connected in a Master/Slave conguration. This
controller has five operating modes: Sound Active mode, Auto mode,
RGB Dimmer mode, Static Color mode and DMX control mode.
Customer Support: ADJ Products, LLC provides a customer sup-
port line, to provide set up help and to answer any question should you
encounter problems during your set up or initial operation. You may
also visit us on the web at www.adj.com for any comments or sugges-
tions. Service Hours are Monday through Friday 8:00 a.m. to 4:30 p.m.
Pacic Standard Time.
Voice: (323) 582-3322
Fax: (323) 582-3108
E-mail: support@adj.com
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Caution! There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
ADJ Products, LLC.
PLEASE recycle the shipping carton when ever possible.
1/13
Содержание
- Caution 1
- Customer support 1
- Introduction 1
- Unpacking 1
- User instructions 1
- Warning 1
- Data cable dmx cable requirements for dmx operation 3
- Dmx 512 3
- Notice 3
- Ower supply 3
- Pin xlr dmx connectors 3
- Special note line termination 3
- Auto run mode 4
- Ch 4 is displayed this is the 14 channel dmx mode ch 4 is displayed this is the 14 channel dmx mode 4
- Ch 6 is displayed this is the 192 channel dmx mode ch 6 is displayed this is the 192 channel dmx mode 4
- Choose one of the three colors to remain static or adjust the intensity of each color to make your own color 4
- Dmx mode 4
- Is displayed this is the 5 channel dmx mode is displayed this is the 5 channel dmx mode 4
- Is displayed this is the 7 channel dmx mode is displayed this is the 7 channel dmx mode 4
- Led pixel 4c operating instructions 4
- Operating modes 4
- Please see pages 14 20 for dmx values and traits 5 after you have chosen your desired dmx channel mode 4
- Rgb dimmer mode 4
- Sound active mode 4
- There are 2 different auto modes to choose from color fade color change and both modes running together the running speed is adjustable in all 2 modes 4
- To run the 14 channel mode press the mode button until to run the 14 channel mode press the mode button until 4
- To run the 192 channel mode press the mode button until to run the 192 channel mode press the mode button until 4
- To run the 5 channel mode press the mode button until ch 5 4
- To run the 7 channel mode press the mode button until ch 7 to run the 7 channel mode press the mode button until ch 7 4
- Default running mode 5
- Either on or of 3 press the up or down buttons to either activate the remote func tion on or deactivate it off 5
- Infrared receiver 5
- Led display inversion 5
- Led display on off 5
- Led pixel 4c operating instructions 5
- Plug the fixture in and press the mode button until dxxx is dis played 2 press the set up button until defa is displayed 3 press the up and down buttons simultaneously press the mode button to exit 5
- Plug the fixture in and press the mode button until dxxx is dis played 2 press the set up button until stnd is displayed 3 press the up or down buttons to flip the display 180 5
- Static color mode 5
- Xxx represents either on or off 5
- Master slave operation 6
- Channel value function 7
- Red 0 255 0 100 2 green 0 255 0 100 3 blue 0 255 0 100 4 master dimmer 0 255 0 100 5 sound activity strobing 0 no function 1 5 sound active 6 10 no function 11 255 strobing slow fast 7
- A d j supply europe b v 12
- Adj products llc 12
- Auto sensing voltage 12
- Channel mode 14 channel 7 channel mode 14 channel 12
- Dimensions 10 5 l x 8 w x 3 5 h 12
- Dmx channels 4 dmx modes 5 channel mode 12
- Ew kerkrade 12
- Junostraat 2 12
- Led pixel 4c specifications 12
- Led pixel 4c warranty 12
- Mode and 192 channel mode mode and 192 channel mode 12
- Model led pixel 4c 12
- Netherlands 12
- Please note specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice 12
- Power cord daisy chain 8 controllers max fuse 2 amp 12
- Power draw 72w 12
- S eastern ave los angeles ca 90040 usa 12
- Service adj eu www adj com 12
- Tel 31 45 546 85 00 fax 31 45 546 85 99 12
- Tel 323 582 2650 fax 323 725 6100 12
- This fixture contains a automatic volt age switch which will auto sense the voltage when it is plugged into the power source 12
- Voltage 100v 240v 50 60hz 12
- Warranty 1 year 365 days 12
- Web www adj com e mail info adj com 12
- Weight 5lbs 2kgs 12
- Working position any safe working position 12
- X 200 x 80mm 259 x 200 x 80mm 12
