ADJ Products, LLC - www.adj.com - LED Pixel 4C User Manual Page 8
LED Pixel 4C Operating Instructions
LED Pixel 4C Operating Instructions
ADJ Products, LLC - www.adj.com - LED Pixel 4C User Manual Page 7
Operating Modes:
The LED Pixel 4C has five operating modes:
• DMX control mode - This function will allow you to control each
individual fixtures traits with a standard DMX 512 controller.
• RGB DimmerMode - Choose one of the three colors to remain
static or adjust the intensity of each color to make your own color.
• Sound-Active mode - The unit will react to sound. There are 24
sound active programs.
• Auto Mode - There are 2 different Auto Modes to choose from.
• Static Color Mode - Choose 1 of 7 colors to remain static.
DMX Mode:
Operating through a DMX controller gives the user the freedom to create
their own programs tailored to their own individual needs. This function
also allows you to use your fixtures as spot lights. The LED Pixel 4C has
4 DMX modes: 5 Channel mode, 7 Channel mode, 14 Channel mode,
and a 192 Channel mode. See pages 14-20 for each modes’ DMX traits.
1. This function will allow you to control each individual fixture’s traits
with a standard DMX 512 controller.
2. To run your fixture in DMX mode press the MODE button until
“A.XXX” is displayed. “XXX” represents the current displayed ad-
dress. Use the UP or DOWN buttons to select your desired DMX
address, then press the SETUP button to select your DMX Channel
mode.
3. Use the UP or DOWN buttons to scroll through the DMX Channel
modes. The Channel modes are listed below:
To run the 5 Channel Mode, press the MODE button until “Ch.05”
is displayed. This is the 5 Channel DMX Mode.
To run the 7 Channel Mode, press the MODE button until “Ch.07”
is displayed. This is the 7 Channel DMX Mode.
To run the 14 Channel Mode, press the MODE button until
“Ch.14” is displayed. This is the 14 Channel DMX Mode.
To run the 192 Channel Mode, press the MODE button until
“Ch.16” is displayed. This is the 192 Channel DMX Mode.
4. Please see pages 14-20 for DMX values and traits.
5. After you have chosen your desired DMX Channel mode plug in
the fixture via the XLR connections to any standard DMX controller.
RGB Dimmer Mode:
1. Plug the fixture in and press the MODE button until “d-XX” is dis-
played. “XX” represents the current LED Pixel Tube being controlled.
If “d-FU” is displayed then all of the tubes are being controlled. If
“d-01” is displayed, you are controlling the tube connected to port 1.
If “d-02” is displayed, you are controlling the tube connected to port
2. If “d-03” is displayed, your controlling the tube connected to port
3. If “d-04” is displayed, you are controlling the tube connected to
port 4. After deciding what tube to control press the SET UP button.
2. When “r.XXX” is displayed you are in Red dimming mode. Press the
UP and DOWN buttons to adjust intensity. After you have finished
adjusting the intensity, or if you would like to skip to the next color,
press the SET UP button.
3. When “G.XXX” is displayed you are in Green dimming mode. Press
the UP and DOWN buttons to adjust intensity.
4. When “b.XXX” is displayed you are in Blue dimming mode. Press the
UP and DOWN buttons to adjust intensity.
5. After you have adjusted the RGB colors to make your desired color
you can then activate strobing by pressing the SET UP button to
enter the Flash (strobe) mode.
6. “FS.XX” will be displayed, this is Flash mode. The Flash can be
adjusted between “FS.00” (flash off) to “FS.15” (fastest flash).
Sound Active Mode:
In this mode the LED Pixel 4C will react to sound. There are 24 sound
active programs to choose from. The sound sensitivity can also be
adjusted.
1. Plug the fixture in and press the MODE button until “SoXX” is dis-
played. “XX” represents the sound active mode (1-24) currently dis-
played. Use the UP or DOWN buttons to scroll through the 24 sound
active programs.
2. When you have found your desired sound active program press the
SET UP button to adjust the sound sensitivity. When you press SET
UP, “SJ-X” will be displayed. Use the UP or DOWN buttons to adjust
the sensitivity. “SJ-1” is the least sensitive, “SJ-8” is the most sensi-
tive.
Auto Run Mode: There are 2 different Auto Modes to choose from;
Color
Fade, Color Change, and both modes running together.
The
running
speed is adjustable in all 2 modes.
1. Plug the fixture in and press the MODE button until either “AFXX”,
or “AJXX” is displayed. Press the SET UP button to switch between
