AMERICAN DJ LED Pixel 4C [7/12] Channel value function

ADJ Products, LLC - www.adj.com - LED Pixel 4C User Manual Page 13 ADJ Products, LLC - www.adj.com - LED Pixel 4C User Manual Page 14

SET ADDRESS - Press this button to set the DMX address. Press

this button first, then press the numbers to set the address.

Example: Set DMX Address 1 Press “S-0-0-1”

Set DMX Address 245 Press “S-2-4-5”

R G B - Press either one of these buttons and the press the “+” or “-”

to adjust the brightness or use the number buttons to input a 3 num-

ber intensity degree. Press the Flash button to activate strobing and

use the “+” and “-” buttons to adjust the strobe speed.

create their own programs tailored to their own individual needs.

Follow the directions below to set your DMX Mode and address.

1. Before connecting to an DMX controller, your fixture has different

DMX channel modes, please select your desired mode by press-

ing the DMX Mode button, then using the “+” or “-” buttons to

scroll through the DMX Channel Modes. Set the mode before you

address the fixture. See the bottom of this page for the DMX

modes.

2. After you have selected your mode, set the DMX address for the

fixture by pressing the “S” button. When the “S” button is pressed

3. Now you may connect the fixture via the XLR connections to any

standard DMX controller. Please see pages 14-20 to for a detailed

descriptions of the DMX modes, values, and traits.

LED Pixel 4C ADJ LED RC Operation

Channel Value Function

1 RED

0 - 255 0% - 100%

2 GREEN

5 SOUND ACTIVITY/STROBING

0 NO FUNCTION

1 - 5 SOUND ACTIVE

6 - 10 NO FUNCTION

11 - 255 STROBING SLOW - FAST

LED Pixel 4C 5 Channel - DMX Values & Functions
