ADJ Products, LLC - www.adj.com - LED Pixel 4C User Manual Page 15 ADJ Products, LLC - www.adj.com - LED Pixel 4C User Manual Page 16
Channel Value Function
4 COLOR CHANGE MODE CONT.
53 - 63 COLOR CHANGE 6
64 - 74 COLOR CHANGE 7
75 - 84 COLOR CHANGE 8
85 - 95 COLOR CHANGE 9
96 - 106 COLOR CHANGE 10
107 - 117 COLOR CHANGE 11
118 - 127 COLOR CHANGE 12
128 - 138 COLOR CHANGE 13
139 - 148 COLOR CHANGE 14
149 - 159 COLOR CHANGE 15
160 - 170 COLOR CHANGE 16
171 - 180 COLOR CHANGE 17
181 - 191 COLOR CHANGE 18
192 - 202 COLOR CHANGE 19
203 - 212 COLOR CHANGE 20
213 - 223 COLOR CHANGE 21
224 - 234 COLOR CHANGE 22
235 - 244 COLOR CHANGE 23
245 - 255 COLOR CHANGE 24
COLOR FADE MODE
0 - 10 COLOR FADE 1
11 - 20 COLOR FADE 2
21 - 31 COLOR FADE 3
32 - 42 COLOR FADE 4
43 - 52 COLOR FADE 5
53 - 63 COLOR FADE 6
64 - 74 COLOR FADE 7
75 - 84 COLOR FADE 8
85 - 95 COLOR FADE 9
96 - 106 COLOR FADE 10
107 - 117 COLOR FADE 11
118 - 127 COLOR FADE 12
LED Pixel 4C 7 Channel - DMX Values & Functions
Channel Value Function
1 MASTER DIMMER
0 - 255 0% - 100%
2 STROBING/PROGRAM SPEED/
SOUND SENSITIVITY
0 - 27 STROBING OFF
28 - 255 STROBING SLOW - FAST
0 - 255 PROGRAM SPEED SLOW - FAST
0 - 31 SOUND SENSITIVITY OFF
32 - 255 SOUND SENSITIVE LEAST - MOST
3 DIMMING/STATIC COLOR SELECT/
COLOR CHANGE SELECT/
COLOR FADE SELECT
0 - 51 DIMMER MODE
52 - 102 COLOR MACRO MODE
103 - 153 COLOR CHANGE MODE
154 - 204 COLOR FADE MODE
205 - 255 SOUND ACTIVE MODE
4 COLOR MACROS & MODES
COLOR MACROS
0 - 31 BLACKOUT
32 - 63 RED
64 - 95 GREEN
96 - 127 BLUE
128 - 159 YELLOW
160 - 191 PURPLE
192 - 223 CYAN
224 - 255 WHITE
COLOR CHANGE MODE
0 - 10 COLOR CHANGE 1
11 - 20 COLOR CHANGE 2
21 - 31 COLOR CHANGE 3
32 - 42 COLOR CHANGE 4
43 - 52 COLOR CHANGE 5
LED Pixel 4C 7 Channel - DMX Values & Functions
