Mystic LED™ Specifications
Model:
Mystic LED™
SPECIFICATIONS:
Voltage: 120V~60Hz / 230V~50Hz
LEDs: 224 5mm LEDs (88 Red, 48 Green,
& 88 Blue)
Fuse: 3 Amp
Weight: 10bs./ 4.5Kgs.
Dimensions: 18.5” (L) x 14.75” (W) x 14.75” (H)
Colors: RGB
Working Position: Any safe working position
Warranty: 3 Year (1095 days)
Please Note: Specications and improvements in the design of
this unit and this manual are subject to change without any prior
written notice.
©American DJ Supply
American DJ World Headquarters:
6122 S. Eastern Ave. Los Angeles, CA 90040 USA
Tel: 323-582-2650 / Fax: 323-582-2610
Web: www.americandj.com / E-mail: info@americandj.com
American DJ Europe
Junostraat 2
6468 EW Kerkrade
Netherlands
service@americandjeurope.com / www.americandjeurope.com
Tel: +31 45 546 85 00 / Fax: +31 45 546 85 99
©American DJ Supply® - www.americandj.com - Mystic LED™ User Manual Page 15
