Accessories
16
Antennas and accessories
The following antenna components are available as accessory parts.
Omni-directional antennas
• A 1031-U, passive omni-directional antenna, article no. 004645
Directional antennas
• A 2003 UHF, passive directional antenna, article no. 003658
• AD 1800, passive directional antenna, 1.8 GHz range, article no. 504916
Antenna splitter
►
• ASA 214, active antenna splitter 2×1:4
• ASA 214-UHF variant, 470 – 870 MHz, article no. 508241
• ASA 214-1G8 variant, 1785 – 1800 MHz, article no. 508242
Antenna amplifiers
• AB 3700, broadband antenna amplifier, article no. 502196
• AB 3, antenna amplifier, up to 42 MHz bandwidth
• AB 3-A variant, frequency range A, article no. 502567
• AB 3-A1 variant, frequency range A1, article no. 507367
• AB 3-B variant, frequency range B, article no. 502568
• AB 3-C variant, frequency range C, article no. 502569
• AB 3-D variant, frequency range D, article no. 502570
• AB 3-E variant, frequency range E, article no. 502571
• AB 3-G variant, frequency range G, article no. 502572
• AB 3-GB variant, frequency range GB, article no. 504680
• AB 3-K variant, frequency range K, article no. 505550
• AB 3-1G8 variant, frequency range 1G8, article no. 504915
• AB 4, antenna amplifier, up to 88 MHz bandwidth
Available from the end of 2018
Antenna cables
• GZL 1019, BNC/BNC coaxial cable, antenna cable with 50 Ω character-
istic (wave) impedance
• GZL 1019-A1 variant, 1 m (3 ft), article no. 002324
• GZL 1019-A5 variant, 5 m (16 ft), article no. 002325
• GZL 1019-A10 variant, 10 m (32 ft), article no. 002326
