26 en | Technical data

IPX Series DSP Multichannel Networking Power

Amplifier

2018.04 | 01 | F.01U.330.705 Installation manual Bosch Security Systems, Inc.

A-weighted, analog input 115 dB

A-weighted, digital input 118 dB

Output Noise

A-weighted, analog input < -70 dBu

A-weighted, digital input < -73 dBu

CONNECTIVITY

Analog Audio Input/Thru

Type 2 x 6-pin Euroblock, male

Maximum Input Level +21 dBu

Input Impedance, active balanced 20 kΩ

Reference level equal to digital input +21 dBu for 0 dBFS

Speaker Output 1 x 8-pin Euroblock, 6 mm, female

GENERAL

Power Consumption

Rated power consumption (see BTU

table)

2250 W

1/8 Maximum Output Power at 4 Ω 2850 W

Idle Mode (no input signal) 110 W

Standby Mode < 19 W

Dimensions

(W x H x D), mm

483 x 88.1 x 514.2

Weight 18.3 kg (40.3 lb)

Shipping Weight 20.5 kg (45.1 lb)

Amplifier at rated conditions, Low-Z Normal operation mode, all channels driven, 4 Ω loads,

Analog input, 32 dB Gain, 48 kHz sample rate, unless otherwise specified.

Test signal for max. output power according IHF-A-202 (Dynamic-Headroom, burst 1 kHz/20

ms on/480 ms off/low level -20 dB).
