28 en | Technical data

IPX Series DSP Multichannel Networking Power

Amplifier

2018.04 | 01 | F.01U.330.705 Installation manual Bosch Security Systems, Inc.

GPIO Control Port

Type 1 x 8-pin Euroblock, male

Ports and Operating Modes 3 x GPIO, switchable Analog In/Digital In/Digital Out

Analog Input Range 0 V to +13 V, 40 kΩ input resistance

Digital Input Limits ON: < 1.5 V

OFF: > 2.0 V, internal Pull Up (10 kΩ)

Digital Outputs ON: Output switched to GND, max. 200 mA

OFF: Open Collector (40 kΩ to GND)

Reference Voltage Output +10 V, max. 200 mA, supervised, short circuit protected

READY/FAULT contact Galvanic isolated relay, max. 30 VDC/500 mADC

GENERAL

User Interface

Display Black/white OLED 256 x 64 pixel

Front panel indicators 4 x status LEDs (POWER, STANDBY, FAULT, OMNEO)

Front panel operating elements 3 buttons (UP, ENTER, DOWN)

Rear panel indicators 1 x status LED (STATUS)

Rear panel operating elements Mains Switch

Power Requirements 100 V to 240 V, 50 Hz to 60 Hz AC

Power Supply Topology Switching Mode Power Supply with digital controlled Power Factor

Correction

Protections Audio Limiters, High Temperature, DC, HF, Short Circuit, Back-EMF, Peak

Current Limiters, Inrush Current Limiters, Turn-on Delay, Mains Circuit

Breaker Protection, Mains Over-/Under voltage Protection

Cooling Front-to-rear, temperature controlled fans, supervised

Ambient Temperature Limits +5 °C to +40 °C (+40 °F to +105 °F)

IEC Protection Class Class I (grounded)

Electromagnetical Environment E1, E2, E3

Color Black

8.6 Mains operation & resulting temperature

The power drawn from the mains network is converted into output power to feed the

connected loudspeaker systems and into heat. The difference between power consumption

and dispensed power is called power dissipation (Pd). The amount of heat resulting from

power dissipation might remain inside of a rack-shelf and needs to be diverted using

appropriate measures.

For further details refer to the mains operation & resulting temperature tables.
