IPX Series DSP Multichannel Networking Power

Amplifier

Technical data | en 27

Bosch Security Systems, Inc. Installation manual 2018.04 | 01 | F.01U.330.705

8.5 IPX5:4, IPX10:4, IPX10:8, and IPX20:4

DIGITAL SIGNAL PROCESSING

Sampling rate 48 kHz/96 kHz, OMNEO/Dante synchronized

Signal delay/latency

Analog In to Speaker Out, 48 kHz/96

kHz

0.70 ms/0.53 ms

Dante Network Latency typ. 1.00 ms

Signal Processing

User EQ 12 filters per channel, selectable as PEQ, Lo-Shelv, Hi-Shelv, Lo-ShelvQ,

Hi-ShelvQ, Hi-Pass, Lo-Pass and Notch; 2 filters of them with additional

asymmetric filter type

User Delay 0 to 2000 ms per channel (units: µs, ms, s, cm, m, inches, feet)

Array EQ 5 filters per channel, selectable as PEQ, Lo-Shelv, Hi-Shelv, Lo-ShelvQ, Hi-

ShelvQ, Hi-Pass, Lo-Pass, and All-Pass

Array Delay 0 to 500 ms per channel (units: µs, ms, s, cm, m, inches, feet)

Speaker EQ 10 filters per channel, selectable as PEQ, Lo-Shelv, Hi-Shelv, Hi-Pass, Lo-

Pass and All-Pass

Speaker X-Over Hi-Pass, and Lo-Pass per channel, 6/12/18/24/30/36/42/48 dB Bessel/

Butterworth, 12/24/48 dB Linkwitz-Riley; Alignment Delay, 0 to 20 ms per

channel

Speaker FIR Up to 1025 taps, Linear Phase Filter, Linear Phase Brickwall X-Over

Speaker Limiters Peak Anticipation Limiter and RMS/TEMP Limiter per channel

Other Functions Source Selection and Mix, Level, Mute, Polarity, Sine and Noise

Generator, Pilot Tone Generator and Detection, Level Meters, Impedance

Measurement and Load Monitoring

Memory

DSP Presets 1 Factory + 20 User

Speaker-Pool Presets 30 Speaker Settings

Source Supervision and Fallback Pilot Tone supervision at Analog and OMNEO/Dante inputs, switchover to

alternative Source Selection

CONNECTIVITY

Network

Type 2 x Neutrik EtherCON/RJ45, redundant PRIMARY/SECONDARY

General 1000base-T/100base-TX, integrated switch

Network Audio Inputs 8 channels, 48/96 kHz, OMNEO/Dante format

Network Audio Outputs (Monitor) 2 channels, 48/96 kHz, OMNEO/Dante format

Mains Input 1 x Neutrik powerCON-HC
