Overall Settings (Menu)
10
Parameter
Explanation
SW CC (ON/OFF SW CC)
MEM CC (MEMORY CC)
CTL1 CC
CTL2 CC
EXP CC
(EXPRESSION CC)
Species the controller number
corresponding to each controller.
OFF, 1–31, 64–95
EFX SW CC
Directly turns the eect on/o.
MIDI THRU
Species whether MIDI messages received
at the MIDI IN connector are retransmitted
without change from the MIDI OUT
connector (ON) or are not retransmitted
(OFF).
CONTRAST
Adjusts the contrast of the display.
1–10
PC#1–128
Species the memory that is selected by
each incoming program change.
OFF, MEM, M-1–4
PC# transmitted from the EQ-200
Memory Program number
MAN
1
MEMORY 1–4
2–5
About STRUCT (STRUCTURE)
STRUCT (STRUCTURE)= PARA (PARARELL), LINK = ON
Operates as a stereo EQ.
INPUT A
EQ A
EQ B
OUTPUT A
OUTPUT B
Linked
INPUT A
INPUT B
EQ A
EQ B
OUTPUT A
OUTPUT B
Linked
