![ASHLY MQX-2310 [10/12] Specifications](/views2/2008389/page10/bga.png)
Page - 10 Operator Manual – MQX-2310 Equalizer
Copyright© 2012 – Ashly Audio Inc.
Specifications
Specification
MQX-2310
Type
Active Balanced
Impedance
20KΩ
Max Level
+23dBu
Connectors
1/4” Phone Jack (TRS), XLR, Euroblock
Output
Type
Servo-Balanced
Source Impedance
100Ω
Min Load Impedance
200Ω
Max Level
+23 dBu
Connectors
1/4” Phone Jack (TRS), XLR, Euroblock
Overall
Frequency Response
20Hz – 20kHz ±0.25dB
THD
<.01%@+20dBu
IM Distortion (SMPTE)
<.01%@+20dBu
Output Hum & Noise (unweighted)
-94dBu
Channel Separation
>85dB @ 1Khz
Gain Control
-∞ to +6dB
Filters
Type
Constant Q/Wein Bridge
Number
31
Bandwidth
1/3 Octave
Tolerance
±3%
Range
±6dB, ±15dB (switchable)
Subsonic Filter 18dB/Octave @ 40Hz
Power Requirements
Nominal Voltage
100-240 VAC (50-60 Hz)
Minimal Voltage
85 VAC
Power
30W
Physical
Shipping Weight
16 lbs (7.3kg)
Dimensions
19”Lx3.5”Hx8”D (483 x 89 x 203mm)
