M 147 Tube
two-stage active filtering at the switching regula-
tor‘s output ensure high quality operating voltag-
es with a minimum of unwanted interfering volt-
ages.
The signal output of the power supply unit is pro-
vided with special protective circuitry so that the
microphone can be connected to audio inputs with
48 V phantom powering without any problems.
The load on the phantom power source will be ap-
prox. 1 mA.
2.2 Getting Started
The M 147 Tube comes complete with KT 8 eight-
core microphone cable, N 149 A power supply
unit, SG 1 swivel mount and an aluminium case.
The stand connector of the SG 1 swivel mount has
a 5/8"-27 internal (female) thread and comes
complete with an adaptor to convert to 1/2" and
3/8" threads.
A cloth dustcover is included to protect the micro-
phone capsule. This provides breathable, effec-
tive protection against contamination if the micro-
phone goes unused for long periods.
When hooking up the microphone, the order in
which the cables are connected does not matter.
A sensor in the power supply ensures that the op-
erating voltages are not run up until the micro-
phone is connected properly. The LED on the pow-
er supply then changes from a low glow to shine
brightly.
Within a few minutes, at the latest, the tube in the
M 147 Tube reaches its stable operating condition
and then evidences its particularly low residual
noise level.
External phantom power, if present, does not de-
tract from the performance of the M 147 Tube. If an
external phantom power source is switched on or
off, only a short, slight rise in the residual noise
level will result.
The on/off switch of the N 149 A functions as a
secondary voltage interrupt for the feeds from the
built-in mains unit. To save energy, the N 149 A
should be unplugged from the wall outlet if it is
not in operation for an extended period.
The M 147 Tube must only be operated with the Neu-
mann power supplies N 149, N 149 A or N 149 V.
2.1 Additional Information on the M 147 Tube
Circuit Design
In contrast to other tube microphones, the
M 147 Tube uses a combination of a specially se-
lected triode and state-of-the-art circuitry. The
developers‘ aim was both to utilize the advanta-
geous properties of a vacuum tube for amplifying
the capsule signal and to exclude any interference
from other parts of the circuitry when the ampli-
fied signal is fed to the microphone output. This
is why the M 147 Tube – unlike conventional tube
microphones – does not use an output transform-
er but an integrated amplifier to drive the differ-
ent output loads. This special audio amplifier fea-
tures an extremely low THD, low self-noise and
high current capacity. Thus, the vacuum tube is
entirely decoupled from the microphone output,
and the typical tube characteristic can be used for
processing highest input signal levels. In contrast
to conventional tube microphones the high output
current of the M 147 Tube allows cable lengths of
up to 300 m without risking a deterioration of sig-
nal quality.
The tube amplifies the capsule voltage by about
10 dB to exclude any remaining impact of the elec-
tronics on the microphone signal. Despite this am-
plification the dynamic range of the M 147 Tube
remains very wide as the microphone delivers a
peak output voltage of ± 10 V at 20 mA.
During its entire life, the operating point of the
tube is kept stable. This refers both to the anode
current and to the heater voltage which is stabi-
lized by a control loop in the power supply unit.
Cable losses of up to 4 V DC
–
which corresponds
to a cable length of approx. 100 m between the
microphone and the power supply unit – are de-
tected and compensated for by a sensor line. A
breakdown of this line due to a short-circuit or an
open circuit is not dangerous as the heater volt-
age would automatically be reduced and all oth-
er voltages switched off. To ensure a long life, the
tube is heated very gently by current limiting
with fold-back characteristic.
The operating voltages for the M 147 Tube are de-
livered by the power supply unit N 149 A using a
switching regulator. Analog pre-controlling and
2.1 Einige Zusatzinformationen zur
Schaltungstechnik im M 147 Tube
Im Unterschied zu üblichen Röhrenmikrophonen
wurde beim M 147 Tube eine besonders ausgesuch-
te Triode mit modernster Schaltungstechnik kom-
biniert. Ziel der Entwicklung war, die besonderen
Übertragungseigenschaften einer Röhre zu nut-
zen, und das hiermit verstärkte Kapselsignal kon-
trolliert, unverfälscht und rückwirkungsfrei an den
Mikrophonausgang zu bringen. Daher wird der bei
Röhrenmikrophonen übliche Ausgangsübertrager
nicht verwendet. Statt dessen wird zum Treiben der
unterschiedlichen Ausgangslasten ein besonders
für Audiosignale geeigneter integrierter Verstär-
ker mit sehr geringen Verzerrungen, sehr kleiner
Rauschspannung und hoher Stromkapazität einge-
setzt. So ist die Röhre völlig vom Mikrophonaus-
gang entkoppelt und wird mit ihrer typischen
Kennlinie bis zu sehr hohen Pegeln für die Ein-
gangssignalaufbereitung nutzbar. Im Gegensatz zu
herkömmlichen Röhrenmikrophonen sind aufgrund
der hohen Ausgangsstromkapazität Kabellängen
bis zu insgesamt 300 m erlaubt, ohne Einbußen in
der Signalqualität in Kauf nehmen zu müssen.
Die Röhre verstärkt die Kapselspannung um ca.
10 dB und schließt Resteinflüsse der nachgeschal-
teten Elektronik auf die Signalübertragung des
Mikrophons gänzlich aus. Dennoch wird ein sehr
hoher Dynamikumfang bewältigt, da eine Spitzen-
ausgangsleistung von ± 10 V bei 20 mA zur Verfü-
gung steht.
Der ideale Arbeitspunkt der Röhre wird während
der gesamten Lebensdauer stabilisiert. Das be-
trifft sowohl den Anodenstrom als auch die Heiz-
spannung, die über einen Regelkreis im Netzge-
rät konstant gehalten wird. Im Mikrophonkabel
entstehende Spannungsabfälle bis zu 4 V = – das
entspricht ca. 100 m Kabel zwischen Mikrophon
und Netzgerät – werden durch eine Sensorleitung
erfasst und ausgeglichen. Auch eine Störung die-
ser Leitung durch Kurzschluss oder Unterbrechung
ist ungefährlich, da für diesen Fall eine Absen-
kung der Heizspannung und eine Abschaltung al-
ler weiteren Betriebsspannungen erfolgt. Das Auf-
heizen der Röhre erfolgt in Hinblick auf eine lan-
ge Lebensdauer schonend über eine rückläufige
Strombegrenzung.
Die für das Mikrophon benötigten Betriebsspannun-
gen werden aus dem Universal-Netzgerät N 149 A
unter Benutzung eines Schaltspannungsreglers ge-
wonnen. Eine analoge Vorregelung und doppelstu-
fige aktive Filterung am Ausgang des Schaltreglers
sorgen für Betriebsspannungen hoher Qualität mit
sehr geringen überlagerten Störspannungen.
Der NF-Ausgang des Netzgerätes ist mit besonde-
ren Schutzmaßnahmen versehen, die einen Be-
trieb des Mikrophons ohne jegliche Einschränkung
an mit 48 V-Phantomspeisung belegten Modulati-
onsdosen ermöglichen. Hierbei wird die Phantom-
speisung mit ca. 1 mA belastet.
2.2 Inbetriebnahme
Das M 147 Tube wird als Set zusammen mit dem
8-adrigen Mikrophonkabel KT 8, dem Netzgerät
N 149 A und dem Stativgelenk SG 1 in einem Alu-
minium-Koffer geliefert. Das Stativgelenk SG 1 be-
sitzt ein 5/8"-27-Gang Innengewinde mit einem
Reduzierstück für 1/2"- und 3/8"-Gewinde.
Zum Schutz der Mikrophonkapsel ist ein Textil-
Staubschutz beigefügt. Wird das Mikrophon länge-
re Zeit nicht benutzt, sorgt dieser für einen luft-
durchlässigen, effektiven Schutz vor Verschmut-
zung.
Zur Inbetriebnahme des Mikrophones ist die Rei-
henfolge des Anschließens der Kabel unerheblich.
Eine Sensorik im Netzgerät sorgt dafür, dass die
Betriebsspannungen erst bei funktionstüchtigem
Anschluss des Mikrophones hochgefahren werden.
Die LED im Netzgerät wechselt dann vom Glimm-
zustand auf ein helles Leuchten über.
Nach spätestens einigen Minuten hat die Röhre im
M 147 Tube ihren stabilen Betriebszustand erreicht
und weist dann ihren besonders niedrigen Eigen-
geräuschpegel auf.
Eine eventuell anliegende externe Phantomspei-
sung beeinträchtigt die Funktion des M 147 Tube
nicht. Wird eine externe Phantomspeisung an- oder
abgeschaltet, ergibt sich kurzzeitig ein leicht er-
höhter Eigengeräuschpegel.
Der Netzschalter des N 149 A unterbricht die Zu-
leitungen des eingebauten Netzteiles sekundär-
seitig. Zur Stromersparnis sollte das N 149 A bei
längerer Nichtbenutzung vom Stromnetz getrennt
werden.
Das M 147 Tube darf nur mit den Neumann-Spei-
segeräten N 149, N 149 A oder N 149 V betrieben
werden.
