Marshall 2525H MINI JUBILEE [3/27] Front panel functions
FRONT PANEL FUNCTIONS
ENGLISH ENGLISH
2525 MINI JUBILEE - HEAD
2525 MINI JUBILEE - COMBO
1 2 3 4 5 6 7 8 9 10 11
1234567891011
1. INPUT
Use this jack socket to connect your
guitar to the amplier. Use a good quality
screened/shielded guitar cable to help
prevent noise interference.
2. INPUT GAIN
INPUT GAIN adjusts the overall sensitivity
of the input circuit. It controls the gain level
of the clean/crunch Rhythm Clip mode and
the Lead Channel. The pull switch activates
Rhythm Clip mode, providing heavier, more
driven tones.
NOTE: The apparent drop in volume when
Rhythm Clip mode is selected may be
overcome by increasing the level of the
OUTPUT MASTER (Front Panel Function #5).
3. LEAD MASTER
When the Lead Channel is active (Front
Panel Function #5) the LEAD MASTER
control adjusts the output level of the Lead
Channel.
4. LEAD CHANNEL LED
The LED indicator will light and glow red
when the Lead Channel is selected.
5. OUTPUT MASTER / LEAD CHANNEL
The OUTPUT MASTER control adjusts the
output of the preamp section to the power
stage.
The Lead Channel is selected using the
footswitch (supplied). The channel can also
be switched by using the push/pull function
of the OUTPUT MASTER control.
The amount of gain applied to the Lead
Channel can be controlled using the INPUT
GAIN control (Front Panel Function #2).
6. TREBLE
Adjusts the amount of upper frequencies in
the sound.
7. MIDDLE
Adjusts mid-range frequencies in the sound.
High settings will provide a fatter sound.
Lower settings provide a more ‘scooped’
sound, accentuating the Treble and Bass
frequencies.
8. BASS
Adjusts the low frequency content in the
sound.
9. PRESENCE
PRESENCE is a power amp function that
adjusts the ‘brightness’ of the whole
amplier independently of the BASS,
MIDDLE and TREBLE controls.
10. OUTPUT
The three position rocker switch combines
STANDBY and HIGH/LOW output power
functions.
