ADJ DLT15A [15/16] Amplifier section

Model: American Audio® DLT-15A - Professional Powered Sound Reinforcement

Loud Speaker

Speaker Section:

Dimensions: 17.5” (L) x 17.5” (W) x 28.75” (H) / 445mm x 445mm x 730mm

Weight: 60 Lbs. / 27 kgs

Environmental conditions: Operational temperature: 5 to 35˚C (41 to 95˚F)

Operational humidity: 25 to 85% RH (non-condensation)

Storage temperature: -20 to 60˚C (4 to 140˚F)

Frequency Response: 40KHz - 20KHz + (±10dB)

Crossover: 2,100 HZ

Nominal Dispersion: 90˚ x 40˚ (H x V)

Amplifier Section:

Power supply: AC 115v/230v, 50/60Hz

Power consumption: 23 Watts (Stand By)

300 Watts Max Power

Accessories: I.E.C. Power Cord

Input Sensitivity: .775V

Output Sensitvity: 97.4 ±2dB/m/w

Max. SPL: 124dB

Input Impedance:

Balanced: 10KΩ

Unbalanced: 20KΩ

Crossover:

Low Pass: 1917Hz, -3dB 24dB/oct

Low Cut: 2194Hz, -3dB 24dB/oct

S/N Ratio: >80dB

Channel Equalizer:

Bass: +/-15dB

Mid: +/-12dB

Treble: +/-15dB

NOTES:

The specifications are subject to change to any improvement by negotiations in advance.

The parts are subject to change to any improvement within the range of the specifications.

LT-15A Technical Specifications
