American DJ® - www.americandj.com - Revo Sweep™ Instruction Manual Page 15 American DJ® - www.americandj.com - Revo Sweep™ Instruction Manual Page 16
Revo Sweep™ 28 Channel DMX Traits
Channel Value Function
1 RED
1 - 255 0% - 100%
2 GREEN
1 - 255 0% - 100%
3 BLUE
1 - 255 0% - 100%
Revo Sweep™ 3 Channel DMX Traits
Channel Value Function
2 CHASE Cont. (CH. 1 VALUES 120 - 239)
120 - 129 CHASE 12
130 - 139 CHASE 13
140 - 149 CHASE 14
150 - 159 CHASE 15
160 - 169 CHASE 16
170 - 179 CHASE 17
180 - 189 CHASE 18
190 - 199 CHASE 19
200 - 209 CHASE 20
210 - 219 CHASE 21
220 - 229 CHASE 22
230 - 239 CHASE 23
240 - 249 CHASE 24
250 - 255 CHASE 25
3 STROBE (CH. 1 VALUES 0 - 119)
0 - 9 OPEN
10 - 255 STROBING SLOW - FAST
CHASE SPEED
(CH. 1 VALUES 120 - 239)
0 - 9 OPEN
10 - 255 CHASE SPEED SLOW - FAST
3 CHANNEL MODE: The setting of Channel 1 is used with
Channel 2 and Channel 3.
Revo Sweep™ 28 Channel DMX Traits
Channel Value Function
4 WHITE
1 - 255 0% - 100%
5 RED
1 - 255 0% - 100%
6 GREEN
1 - 255 0% - 100%
7 BLUE
1 - 255 0% - 100%
8 WHITE
1 - 255 0% - 100%
9 RED
1 - 255 0% - 100%
10 GREEN
1 - 255 0% - 100%
11 BLUE
1 - 255 0% - 100%
12 WHITE
1 - 255 0% - 100%
13 RED
1 - 255 0% - 100%
14 GREEN
1 - 255 0% - 100%
15 BLUE
1 - 255 0% - 100%
16 WHITE
1 - 255 0% - 100%
17 RED
1 - 255 0% - 100%
18 GREEN
1 - 255 0% - 100%
19 BLUE
1 - 255 0% - 100%
20 WHITE
1 - 255 0% - 100%
