ADJ Revo Sweep [9/10] Channel value function
![ADJ Revo Sweep [9/10] Channel value function](/views2/2008548/page9/bg9.png)
Revo Sweep™ Cleaning
Revo Sweep™ Trouble Shooting
Trouble Shooting: Listed below are a few common problems that
you may encounter, with solutions.
No light output from the unit;
1. Be sure you have connected your unit into a standard 120v wall
outlet.
2. Be sure the external fuse has not blown. The fuse is located on
the bottom panel of the unit.
3. Be sure the fuse holder is completely and properly seated.
Unit does not respond to sound;
1. Low frequencies (bass) should cause the unit to react to sound.
Tapping on the microphone, quiet or high pitched sounds may
not activate the unit.
Fixture Cleaning: Due to fog residue, smoke, and dust cleaning the
internal and external optical lenses and mirror should be carried out
periodically to optimize light output. Cleaning frequency depends on
the environment in which the fixture operates (I.e. smoke, fog residue,
dust, dew). In heavy club use we recommend cleaning on a monthly
basis. Periodic cleaning will ensure longevity, and crisp output.
1. Use normal glass cleaner and a soft cloth to wipe down the out-
side casing.
2. Use a brush to wipe down the cooling vents and fan grill.
3. Clean the external optics and mirror with glass cleaner and a soft
cloth every 20 days.
4. Clean the internal optics with glass cleaner and a soft cloth every
30-60 days.
5. Always be sure to dry all parts completely before plugging the unit
back in.
American DJ® - www.americandj.com - Revo Sweep™ Instruction Manual Page 17 American DJ® - www.americandj.com - Revo Sweep™ Instruction Manual Page 18
Revo Sweep™ Fuse Replacement
First unplug the power. The fuse holder is located next to the power
cord. Using a flat-head screw driver to unscrew the fuse holder.
Remove the bad fuse and replace with a new one.
Revo Sweep™ 28 Channel DMX Traits
Channel Value Function
21 RED
1 - 255 0% - 100%
22 GREEN
1 - 255 0% - 100%
23 BLUE
1 - 255 0% - 100%
24 WHITE
1 - 255 0% - 100%
25 RED
1 - 255 0% - 100%
26 GREEN
1 - 255 0% - 100%
27 BLUE
1 - 255 0% - 100%
28 WHITE
1 - 255 0% - 100%
28 CHANNEL MODE: Each channel is 3 LEDs per Lens. i.e.
Channel 1 is 3 Red LEDs behind the rst lens, Channel 4 is 3
LEDs behind the second lens, .........
