American DJ® - www.americandj.com - Revo Sweep™ Instruction Manual Page 13 American DJ® - www.americandj.com - Revo Sweep™ Instruction Manual Page 14
Revo Sweep™ Operation
2. Using the either the UP or DOWN buttons, nd your desired show.
See page 10 for more details.
3. Press ENTER to conrm.
4. The optional UC3 Controller (not included) may be used to con-
trol different functions including blackout.
Master-Slave Operation (Sound Active): This function will allow
you to link up to 16 units together and operate without a controller. The
units will be sound activated. In Master-Slave operation one unit will
act as the controlling unit and the others will react to the controlling
units programs. Any unit can act as a Master or as a Slave.
1. Using standard XLR microphone cables, daisy chain your units
together via the XLR connector on the rear of the units. Remem-
ber the Male XLR connector is the input and the Female XLR
connector is the output. The rst unit in the chain (master) will use
the female XLR connector only - The last unit in the chain will use
the male XLR connector only. For longer cable runs we suggest a
terminator at the last fixture.
2. On the Master unit tap the MENU button until “SLND” is dis-
played, and press ENTER. Press the UP or DOWN button until
“MAST” is displayed, and press ENTER to conrm. Now, select
your desired operating mode and set that show by pressing the
ENTER button.
3. On the slave units tap the MENU button until “SLND” is dis-
played, select your desired Slave mode and Press ENTER.
4. The slave units will now follow the Master unit.
5. The optional UC3 Controller (not included) may be used to con-
trol different functions including blackout.
Revo Sweep™ 3 Channel DMX Traits
Channel Value Function
1 COLOR/CHASE/SOUND ACTIVE
0 - 119 COLOR
120 - 239 CHASE
240 - 255 SOUND ACTIVE
2 COLOR (CH. 1 VALUES 1 - 119)
0 - 15 OFF
16 - 31 COLOR 1
32 - 47 COLOR 2
48 - 63 COLOR 3
64 - 79 COLOR 4
80 - 95 COLOR 5
96 - 111 COLOR 6
112 - 127 COLOR 7
128 - 143 COLOR 8
144 - 159 COLOR 9
160 - 175 COLOR 10
176 - 191 COLOR 11
192 - 207 COLOR 12
208 - 223 COLOR 13
224 - 239 COLOR 14
240 - 255 COLOR 15
CHASE (CH. 1 VALUES 120 - 239)
0 - 9 OFF
10 - 19 CHASE 1
20 - 29 CHASE 2
30 - 39 CHASE 3
40 - 49 CHASE 4
50 - 59 CHASE 5
60 - 69 CHASE 6
70 - 79 CHASE 7
80 - 89 CHASE 8
90 - 99 CHASE 9
100 - 109 CHASE 10
110 - 119 CHASE 11
Revo Sweep™ UC3 Control
Stand by
Blackout the unit
Function
1. Strobe
2. Sound Synchronous Strobe
3. Sound Asynchronous Strobe
Show
12
Mode
Strobe (LED OFF)
Latch (LED ON)
