Operation
SCALE
This function allows you to experience different scales
when you play certain genres of music that is not comp-
osed based on twelve equal interval.
Press [SCALE] button to enter into scale mode and the
button indicator lights up; The default scale is 001
Pythagor.
There are 6 types of scale to select:
Pythagor, Major, Minor, Meantone, Werckmei, kirnberg.
Press [SCALE] button again to exit scale mode and the
button indicator goes off.
Hold and press [SCALE] for 2 seconds to enter into SCALE
select status. The scale now flashes and the scale number
displayed on LED.
Use [+/YES] or [-/NO] to select the scale type, play the
key from C7~B7 to select scale root.
VOICE
DEMO
SCALE
REVERB/
CHORUS
VOICE
VOICE
STYLE
STYLE
SONG
SONG
Enter scale mode and
the indicator lights up.
Press and hold the button for
2 seconds to enter scale select
status. The indicator is flashing.
Display scale type.
Display scale root.Press the G7 key
C7
B7
VOICE
DEMO
SCALE
REVERB/
CHORUS
Press the button again to exit scale
mode. The indicator goes off.
VOICE
DEMO
SCALE
REVERB/
CHORUS
Number Name Number Name
1 Pythagor
2 Major
3 Minor
4 MeanTone
5 Werckmei
6 Kirnberg
Types of sc ale :
Select the scale type
VOICE
STYLE
SONG
+ / YES
- / NO
BEAT
2、
3、
4、
5、
1、
For example, to select the scale named"Minor"
and set the root key to "G",keep pressing [+/YES]
till "003 " displayed temporarily on the LED,
then press the G7 key to set the root, LED displays
"G","G" stands for "Scale Root".
PEDAL
1、
SUSTAIN Pedal
When you step on the sustain pedal, all notes
played on the keyboard have a lingering effect.
3、
SOFT Pedal
when you step on the soft pedal, all notes played
on the keyboard have a soft effect. The volume is
reduced slightly
2、
SOSTENUTO Pedal
When you step on the pedal, the first note you play
has a sustain effect, but all subsequent notes will
not sustain.
Soft
Pedal
Sostenuto
Pedal
Sustain
Pedal
17
