Physical Specications
A-3
Appendix B
Physical Specications
Keyboard: 88-note, graded hammer-weighted action with velocity sensitive adjustable
keys
Display: 16 character LCD w/ front-panel contrast adjust
Polyphony: 64 Voice Polyphony, dynamically allocated
Multitimbral: 16 parts (one per MIDI channel)
Quick Split/Layer: Easy access with adjustable relative volume
Factory Presets: 128 Programs, taken from the acclaimed PC3 sound set
Factory MIDI Setups: 128 factory setups, plus 128 user setup locations with 4 programmable zones
for splits and layers
Effects: Dozens of complex effect chains taken from the PC3
Controllers: • Pitch touchpad
• Modulation slider
• 1 front panel knob
• 1 stereo switch-pedal input (supports two pedals with Y connector)
• 1 continuous control pedal input
Analog Outputs: • Two 1/4” balanced TRS analog (24-bit DACs)
• +21DBu maximum output
• 400Ω balanced source impedance
• 24-bit D-to-A converters
Analog Inputs • Two 1/4” balanced TRS inputs
• Input impedance 10K unbalanced; 20K balanced
• 1.6Vrms for 19Wrms output per channel
Amplier Speakers Stereo 19W/channel @ <1% THD+N; 48W maximum total power
Two 4 x 6” woofers (in ported enclosure)
Two 1” neodynium magnet dome tweeters
Headphones: Two front panel 1/4” headphone output
8 Vrms maximum output, 47Ω source impedance
MIDI: In, Out
USB: Complete MIDI functionality over USB
User program/setup le transfer to/from PC/Mac
Operating System updates from PC/Mac
Height: 3.4” (8.6 cm)
Depth: 11.4” (28.9 cm)
Length: 43.6” (110.8 cm)
Weight: 24 lb. (11 kg)
Power: External 19VDC 3.4A power supply
