Getting Started
Connecting Pedals
2-7
By default, the right pedal will control sustain as before and the left pedal will control the
sostenuto function. If you’re not familiar with traditional piano technique, the sostenuto
(center) pedal on a grand piano allows one to hold chords in the bass while continuing
to play the melody without the latter notes sustaining. Any keys that are down when you
depress the pedal will sustain when you let go of the keys, but new notes played afterward
will not be sustained. Releasing the pedal puts things back to normal. Of course it can be
programmed to do other functions as well.
Connecting a Control Pedal
A control pedal can be very useful for controlling volume, vibrato, or other effect by foot.
The Kurzweil CC-1 control pedal will work best with the SPS4, but it is also possible to use
third-party control pedals designed for synthesizers. Note that a volume pedal may or may
not be satisfactory depending on how it is constructed.
See Control Pedal Problems on page 12-6 if you are having trouble with your control pedal.
