System Menu

1 - Memory Protect – On, Off

This is set to “On” when the Nord Electro 4D leaves the factory, meaning

that you cannot store any changes to the programs. Set this to Off when

you wish to store your own programs. The System, MIDI, B3 or Rotary

menu settings and the Live memory are not protected by this setting.

Range: On (default), off

2 - Output Routing

If you want to process your sound using external effects or separate

SO - Separated Output. All organs are routed to left output, pia-

nos/samples are routed to the right output.

3 - Transpose

Transpose allows you to globally transpose the pitch of the Electro 4D

up or down in semitone steps.

Range: -/+ 6 semitones (default = 0).

4 - Fine Tune

This allows you to fine tune the pitch of the Nord Electro 4D.

Range: +/- 50 cent (default = 0).

5 - Sustain Pedal Polarity

nected to control Rotor Speed, in case the functionality of your pedal is

reversed (i.e. when the pedal is up, Rotor Speed is fast and vice versa).

Range: CL - Close (default), OP - Open.

7 - Sustain Pedal Mode

If you’re using a single sustain pedal connected to the Sustain Pedal

input you may want to use it for sustain with piano sounds and as a

Rotor Speed switch with organ sounds. In this case, select “rt” (rotor

toggle) with the Up/Down buttons.

If you’re using two separate sustain pedals: one in the Sustain Pedal

Input and one in the Rotor Speed Input you probably want to use the

Rotor Speed is fast for as long as the pedal is down and reverts back

to slow when the pedal is released (or vice versa depending on the

set pedal polarity).

“Toggle” means that the fast/slow rotor speed is switched each time

you activate the pedal, like an on/off switch pedal.

Range: Hd - Hold, (default), tO - Toggle.

9 - Ctrl Pedal Type

The Electro 4D accepts many of the most commonly available control

pedals the Ctrl Pedal input. Select a setting here that matches the

pedal that you use.

6

The Menus

Any settings that you change in the System, MIDI, B3 or Rotary menu will take immediate effect on a global basis, and will be stored until you

change them the next time. Enter the menus by pressing and holding Shift and the System, MIDI, B3 or Rotary button (Prog 1, Prog 2, Prog 3 or

Prog 4). Select a function with the Up/Down buttons and change the setting by pressing and holding Shift and the Up or Down button. Exit the

menus by pressing a second time on the Prog 1, 2, 3 or 4 button.

M The only exception to this is the MIDI Local On/Off setting which always reverts to Local On every time the Electro 4D is powered on.

chaptEr 6 thE MENUs | 17
