System Menu

1 - Memory Protect – On, Off

This is set to “On” when the Nord Electro 4 HP/SW leaves the factory,

meaning that you cannot store any changes to the programs. Set this to

Off when you wish to store your own programs. The System, MIDI, B3

and Rotary menu settings and the Live memories are not protected by

this setting.

Range: On (default), off

2 - Output Routing

and Farf organs and pianos/samples are routed to right output.

SO - Separated Output. All organs are routed to left output, pia-

nos/samples are routed to the right output.

3 - Transpose

Transpose allows you transpose the pitch of the Electro 4 HP/SW up or

down in semitone steps.

Range: -/+ 6 semitones (default = 0).

4 - Fine Tune

This allows you to fine tune the pitch of the Nord Electro 4 HP/SW.

Range: +/- 50 cent (default = 0).

This allows you to change the polarity of a sustain type pedal con-

nected to control Rotor Speed, in case the functionality of your pedal is

reversed (i.e. when the pedal is up, Rotor Speed is fast and vice versa).

Range: CL - Close (default), OP - Open.

7 - Sustain Pedal Mode

If you’re using a single sustain pedal connected to the Sustain Pedal

input you may want to use it for sustain with piano sounds and as a

Rotor Speed switch with organ sounds. In this case, select “rt” (rotor

toggle) with the Up/Down buttons.

If you’re using two separate sustain pedals: one in the Sustain Pedal

how this should operate. “Hold” means that the Rotor Speed is fast

for as long as the pedal is down and reverts back to slow when the

pedal is released (or vice versa depending on the set pedal polarity).

“Toggle” means that the fast/slow rotor speed is switched each time

you activate the pedal, like an on/off switch pedal.

Range: Hd - Hold, (default), tO - Toggle.

9 - Ctrl Pedal Type

Different models of control pedals have different specifications (resis-

tance, offset and linearity). To simplify setup and to optimize the response

of the pedal for the Nord Electro 4 HP/SW, the most common pedal

Any settings that you change in the System, MIDI, B3 or Rotary menu will take immediate effect on a global basis, and will be stored until you

change them the next time. Enter the menus by pressing and holding Shift and the System, MIDI, B3 or Rotary button (Prog 1 - 4), the 1-4 LED will

start blinking. Select a function with the Up/Down buttons and change the setting by pressing and holding Shift and the Up or Down button. Exit the

menus by pressing a second time on the Program button.

M The MIDI Local On/Off setting will always revert to Local On every time the Electro 4 HP/SW is powered up.

cHaPtEr 6 tHE MENUS | 17
