Program and CC dumps
To dump a Program SysEx, or MIDI Controller data via MIDI, either to
another Nord Electro 4 HP/SW or for recording the data into another
MIDI device, proceed as follows:
Sending program dumps
1 Connect the MIDI OUT on the Nord Electro 4 HP/SW to the MIDI
In on the receiving device, or use the USB connection.
2 Set up the receiving device to accept MIDI SysEx and MIDI Con-
troller data.
3 Press Shift + MIDI and select the “Dump One” or “Dump All” menu
item using the Up/Down buttons.
4 If needed, set the receiving MIDI device to “recording mode”.
5 Press the Store button to send the dump to the MIDI Out of Nord
Electro 4 HP/SW. The display will stop flashing once the dump
has been sent.
M For the programs that use the organ sounds, the complete
settings for the sound will be dumped as MIDI SysEx but for
programs using pianos or Samples, all parameters will be sent but
NOT the actual instrument samples.
Therefore, when dumping back a program that uses a piano sound,
make sure the actual instrument samples are also available in the Nord
Electro 4 HP/SW. Otherwise the parameters in the SysEx message will
be applied to another available piano instrument.
Sending MIDI Controller dumps
1 Set up as in steps 1 and 2 in the preceding description.
2 Press Shift + MIDI and select the ‘Send CC” menu item using the
Up/Down buttons.
3 Press the Store button to send the dump to the MIDI Out of Nord
Electro 4 HP/SW. The Display will stop flashing once the dump
has been sent.
Receive MIDI SysEx dumps
Here is how to receive a MIDI SysEx Dump:
1 Connect the MIDI Out on the transmitting device to the MIDI IN on
the Nord Electro 4 HP/SW.
2 Initiate the transmission on the transmitting device.
If the dump contained all Programs (All), it will replace all programs cur-
rently stored in the Nord Electro 4 HP/SW. If the dump contained only
a single program, it will be temporarily placed in the currently selected
program memory location. A dot will appear to in the lower, right corner
to indicate an unsaved edit. You will then have to store the program
manually to a memory location using the Store function (see “Storing a
program” on page 10).
MIDI Controller list
The following is a list of the MIDI Controller numbers used for all knobs
and buttons on the front panel:
Nord Electro 4 HP/SW parameter MIDI CC
Drawbars - Preset 2/Upper
Drawbar 1 16
Drawbar 2 17
Drawbar 3 18
Drawbar 4 19
Drawbar 5 20
Drawbar 6 21
Drawbar 7 22
Drawbar 8 23
Drawbar 9 24
Drawbars - Preset 1/Lower
Drawbar 1 70
Drawbar 2 71
Drawbar 3 72
Drawbar 4 73
Drawbar 5 74
Drawbar 6 75
Drawbar 7 76
Drawbar 8 77
Drawbar 9 78
Organ Model Sel 9
Preset/Split Sel 3
Perc Decay 88
Perc Level 89
Sustain Pedal 64
Control Pedal 11
Rotary Speed 82
Rotary Stop Mode 79
Vib Mode 84
Vib On/Off UP 85
Vib On/Off LO (B3 model) 107
Perc On/Off 87
Perc Third 95
Samp Attack Sel 33
Samp Release Sel 34
Clav EQ Brill On/Off 103
Clav EQ Treble On/Off 104
Clav EQ Medium On/Off 105
Clav EQ Soft On/Off 106
Inst Sel (Organ/Piano) 13
Clav Select 45
Piano Type 12
Piano Model 44
Piano Mono 83
Piano Dynamics 99
Acoustics 98
Oct Shift Organ Upper 27
Oct Shift Organ Lower 28
Oct Shift Piano 29
EQ On/Off 115
EQ Treble 113
EQ Mid 116
EQ Mid Freq 117
EQ Bass 114
Gain 7
Effect 1 Rate 63
Effect 1 Sel 60
Effect 1 On/Off 69
Effect 2 Rate 62
Effect 2 Sel 61
Effect 2 On/Off 80
Speaker/Comp Drive 111
Speaker/Comp Sel 81
Speaker/Comp On/Off 86
Reverb Wet/Dry 102
Reverb Sel 96
Reverb On/Off 97
Delay Rate 92
Delay Ping Pong 93
Delay On/Off 94
22 | Nord ElEctro 4 HP/SW USEr MaNUal oS v1.1x
