B3 Menu
1 - Tonewheel Mode
Sets the level of tonewheel crosstalk and cable leakage artifacts of the
B3 organ model.
The Vintage 3 mode will create noises from the B3 model even if
you don’t play any keys.
Range: u3 – Vintage 3, u2 - Vintage2 (default), u1 - Vintage1,
Cl – Clean
2 - Key Click Level
This sets the amount of Key Click for B3 organ model.
Range: H2 - Higher, HI - High, nO - Normal (default), LO - Low
3 - Key Bounce
This turns on or off the Key Bounce feature. When this is on, the key off
click can be accentuated if the key is released quickly.
Range: On (default), Off
4 - Perc. Fast Decay
Sets the fast mode decay time of the Tonewheel percussion effect.
Range: Ln - Long, nO - Normal (default), SH - Short
5 - Perc. Slow Decay
Sets the slow mode decay time of the Tonewheel percussion effect.
Range: Ln - Long, nO - Normal (default), SH - Short
6 - Perc. Norm Level
Sets the level of the percussion effect in its normal setting.
Range: HI - High, nO - Normal (default), LO – Low
7 - Perc. Soft Level
Sets the level of the percussion effect in its soft setting.
Range: HI - High, nO - Normal (default), LO – Low
8 - Perc Drawbar 9 Cancel
If this is set to cancel, the 9th drawbar will be muted when the percus-
sion is activated, to mimic the behavior of an original organ.
Range: C – Cancel, nO – Normal (default).
Rotary Menu
1 - Rotary Model
There is one rotary model available, with two separate microphone
positions. The 122 is modeled with the microphones placed tradition-
ally a bit away from the speaker. The 122 Close have the microphones
placed closer to the cabinet.
Range: nO - 122 (default), CL - 122 Close
2 - Balance Bass/Horn
This parameter allows you to adjust the balance between the two
separate microphone setups for the bass rotor and treble horn.
Range: H2 - 30 bass/70 horn, H1 - 40/60, nO - 50/50 (default),
b1 - 60 bass/40 horn, b2 - 70/30
3 - Treble Horn Speed
Sets the speed setting (in the fast and slow speed modes) of the rotary
speaker simulation’s treble horn.
Range: HI - High, nO - Normal (default), LO - Low
4 - Bass Rotor Speed
Sets the speed setting (in the fast and slow speed modes) of the rotary
speaker simulation’s bass rotor.
Range: HI - High, nO - Normal (default), LO - Low
5 - Treble Horn Acceleration
Sets the acceleration and retardation time of the rotary speaker simula-
tion’s treble horn.
Range: HI - High, nO - Normal (default), LO - Low
6 - Bass Rotor Acceleration
Sets the acceleration and retardation time of the rotary speaker simula-
tion’s bass rotor.
Range: HI - High, nO - Normal (default), LO – Low
cHaPtEr 6 tHE MENUS | 19
