FBV MkII Advanced User Guide: Getting Started
1•8
FBV Express MkII Calibration Steps
• Start with your FBV device not connected to any USB port or Line 6 device (and, therefore,
powered “off”).
• Press and hold down the “D” labeled footswitch while you “power on” your FBV (by connecting
to your computer’s USB port, or Line 6 device with which you plan on using your FBV). Upon
release of the D footswitch, the FBV Tuner’s numerical display will read “1”.
• Press the on-board pedal forward fully and hold down pedal’s Toe Switch until the Tuner display
changes to “2”. This should occur instantly.
• While holding the pedal in the “heel” (minimum) position, press & release the D footswitch.
The Tuner display will change to “3”.
• Move the pedal to the toe (maximum) position, without clicking the Toe Switch. Allow the
pedal to rest in the toe position (maximum) and press & release the D button. The 7 LEDs above
the Tuner’s numerical display will light.
• Move the pedal and verify that the LEDs above the Tuner’s numerical display sequentially turn
off as the pedal moves to the minimum position, and all sequentially light up when the pedal is
moved to the maximum position.
• If your 7 LEDs do not light up as described, then try repeating these calibration steps. If your
LEDs light up correctly, then calibration was successful - power off your FBV and power it back
on and you are ready to go!
Expression Pedal
FBV Shortboard MkII owners can optionally add a 2nd pedal for even greater control! The Line
6 EX-1 Expression Pedal is designed to work with the FBV Shortboard MkII plugging it into the
Expression Pedal jack on the back of the chassis. The EX-1 can be purchased directly on the Line 6
Online Store, or from most Line 6 dealers.
Note: An Expression pedal does not require any calibration steps.
With the above steps complete you should now be ready to dive into the following chapters with
your Line 6 FBV™ MkII Series Controller! Please see the following chapter that covers the
specific gear you want to control with your FBV.
