FBV MkII Advanced User Guide: Controlling 3rd Party Software
6•5
Once you have all these settings created, go to File > Save to save the preset, and exit the FBV Control
application.
Ableton Live MIDI Input Device Configuration
Next, we need to configure Ableton Live to receive MIDI commands from the FBV Controller device:
Launch the Ableton Live software, and go to Ableton Live > Preferences > MIDI/Sync page (Mac
®
)
or Options > Preferences > MIDI/Sync page (Windows
®
). Here you will see that Live automatically
detects all four of the FBV MIDI Out Ports. You might see additional devices’ MIDI Ports appear here
as well, depending what other MIDI hardware/software you have installed on your computer.
Note that the names of these Ports will appear differently if you are running Mac OS
®
X, Windows
®
XP,
Vista
®
or 7, as shown below.
• Click on the Remote button to the right of the first FBV MIDI Out Port so it is “On”, and then
deselect any other active “On” buttons in the Track, Sync and Remote columns so that all others
are “Off”, as shown in the following screen shots. This allows Ableton to receive MIDI Control
commands from your FBV MIDI Out Port 1.
Turn first FBV Port ON,
and all other Track,
Sync & Remote buttons
OFF
You’ll see all 4 FBV
MIDI Out Ports listed
here as available
“Inputs” into Live
Mac OS® X
