FBV MkII Advanced User Guide: POD X3

2•4

Pedal: The onboard Pedal (as well as a connected Expression Pedal) can actually be assigned to control

either Tone 1, Tone 2, or both Tones, and assigned to different functions (Wah, Volume, Tweak).

Please refer to the following POD X3 System Configuration section for details on how to set up these

pedal behaviors per Tone.

Pedal VOL & WAH Indicators: These two lights at the left of the onboard Pedal indicate the

current mode. When both lights are lit this indicates the Pedal is controlling the assigned TWEAK

parameter. For the TWEAK parameter, you can actually choose from a menu of many effect

mode. You’ll see the onboard Tuner display become active. To exit tuner mode, simply press and release

any channel button (and you’ll also be returned to the same tone preset). Or, pressing the pedal all

the way forward and clicking the toe switch will exit the Tuner, (as well as toggle the pedal control

between WAH and VOL).

TIP: You can also set the “AUDIO” behavior for the Tuner mode on the POD X3 directly on the POD

X3 Tuner page to either MUTE your audible signal or not. (Sure, everyone likes to hear a guitar in tune,

but they don’t necessarily want to hear you tune it!)

Pedal: The onboard Pedal can actually be assigned to control either Tone 1, Tone 2, or both Tones,

and assigned to different functions (Wah, Volume, Tweak). Please refer to the following POD X3

System Configuration for details on how to set up these pedal behaviors per Tone.

your FBV Shortboard or Express Pedal behaviors. On the POD X3, press and hold the OUTPUTS/

Hold for System button to get to the SYSTEM screen.

Page 1 of the POD X3 System screen
