FBV MkII Advanced User Guide: POD X3

2•6

TONE1 PEDAL - Use this TONE1 setting to conﬁgure the two “modes” of operation for Pedal 1 &

Pedal 2 (if Pedal 2 is connected) for Tone 1. The settings here are strictly for Tone 1, and the value you

have set for the PEDAL CNTRL setting (see previous) determines whether Tone 1 will be controlled

or not by your pedal(s). Note that the pedal options differ if you have an FBV Shortboard with an

Expression pedal connected.

The PEDAL TONE1 options for FBV Express and Shortboard without an Expression pedal are

as follows:

• 1-W/V 2-VOL - Pedal 1 controls the Wah or Volume effect’s Position parameter, with the toe

switch toggling between controlling these two effects for Tone 1. Pedal 2 options are not active.

• 1-TWK 2-VOL - Pedal 1 controls the Tweak parameter that is currently assigned for Tone 1.

(See the following TONE1 TWK section.) Pedal 2 options are not active.

• 1-W/V 2-TWK - Pedal 1 controls the Wah or Volume effect’s Position parameter, with the toe

switch toggling between controlling these two effects for Tone 1. Pedal 2 options are not active.

The PEDAL TONE1 options for FBV Shortboard with an Expression pedal are as follows:

• 1-W/OFF 2-VOL - Pedal 1 controls the Wah, with the toe switch toggling the Wah effect on/

off. Pedal 1 performs no function when the Wah is off. Pedal 2 controls the Volume at all times.

• 1-TWK 2-VOL - Pedal 1 controls the Tweak parameter that is currently assigned for Tone 1.

(See the following TONE1 TWK description.) The toe switch performs no function. Pedal 2

controls the Volume for Tone 1.

• 1-W/V 2-TWK - Pedal 1 controls the Wah or Volume effect’s Position parameter, with the toe

switch toggling between controlling these two effects for Tone 1. Pedal 2 controls the Tweak

parameter that is currently assigned for Tone 1. (See the following TONE2 TWK description.)

TONE2 PEDAL - Use these TONE2 settings to conﬁgure the two “modes” of operation for Pedal

1 & Pedal 2 (if Pedal 2 is connected) for Tone 2. The options for the PEDAL TONE2 are the same

as those described in the TONE1 PEDAL section above, but the settings here are strictly for Tone 2,

to provide you with independent pedal behaviors per Tone. The values you have set for the PEDAL

CNTRL setting (see previous description) determine whether Tone 2 will be controlled or not by your

pedal(s). Also note the TONE2 TWK options below to conﬁgure what the TONE2 “Tweak” pedal

options perform.

TONE1 TWK - (Tweak) If you’ve assigned one of the TONE1 PEDAL options to control TWK, this

is where you choose the parameter that will be controlled with that TWK-assigned pedal. The list of

available parameters is too long to list here - turn the knob and see what you ﬁnd!

TONE2 TWK - (Tweak) If you’ve assigned one of the TONE2 PEDAL options to control TWK, this

is where you choose the parameter that will be controlled with that TWK-assigned pedal. The list of

available parameters is too long to list here - turn the knob and see what you ﬁnd!

TONE1 LP SW (Shortboard only) - This LP SW (“Loop Switch”) setting allows you to choose what

the FBV Shortboard FUNCTION1 switch actually controls for Tone 1. (Note that we’ve recently

expanded this to offer more than just a “Loop Switch” option, so don’t the name fool you!) Your

options for Tone 1 are:

• COMP - Toggles Compressor block on/off.

• AMP - Toggles Amp+Cab block on/off.
