FBV MkII Advanced User Guide: Getting Started
1•6
On Windows
®
XP, you may need to click through a few dialogs to install the device driver. Once you
connect the USB cable, you should see Windows
®
XP detect the new device at the bottom right of
your screen:
Next, the Windows
®
Hardware Wizard will launch. Select “No, not this time” then click Next.
In the following screen, select the “Install automatically” option and click Next.
Note that XP recognizes and installs FBV
as a “USB Audio Device”. This is normal
behavior for the Windows® XP USB
Class Compliant Driver.
Next you should see the final dialog telling the installation is complete - click Finish. Your FBV is now
ready to rock!
