FBV MkII Advanced User Guide: Controlling Line 6 POD Farm 2
4•6
manually within POD Farm 2 Plug-In for any of your FBV MkII controls!) You’ll see more about
Local & Global assignments and MIDI Learn in the following sections.
• Pedal Volume - Adjusts both the Tone A Level and Tone B Level faders within the POD Farm 2
Mixer View simultaneously. If your current POD Farm 2 configuration is a single Tone, then only
the Tone A Level fader is controlled. Note that this is a Global MIDI assignment.
FBV Express MkII
POD Farm 2-Express.fbv preset settings, when loaded in the FBV Control application
The above FBV Express MkII MIDI Controller settings perform the following functions with POD
Farm 2:
FBV Express MkII Control POD Farm 2 Pre-configured Model & Parameter
A Selects the previous Setlist, and loads the first Tone Preset within
B Selects the next Setlist, and loads the first Tone Preset within
C Loads the previous Tone Preset within the selected Setlist
D Loads the next Tone Preset within the selected Setlist
Pedal Wah Wahs - Adjusts Position knob
Toe Switch Wahs - On/Off, or Bender effect On/Off
FBV Express MkII Control POD Farm 2 Pre-configured Global Parameter
(POD Farm 2 Standalone Only)
Pedal Volume Adjusts the Mixer Tone A Level and Tone B Level
Pre-configured functions provided in POD Farm 2 by the POD Farm 2-Express.fbv preset settings
• A & B footswitches - These footswitches select the previous and next correspondingly numbered
Setlist, respectively. Each also automatically loads the first Tone Preset within the selected Setlist
(the preset with the number “0” to its left). This allows you to then use the C & D footswitches
to load Tone Presets within the selected Setlist.
• C & D footswitches - These footswitches select the previous and next correspondingly numbered
Tone Preset within the currently selected Setlist, respectively.
Note that no Setlists exist within POD Farm 2 by default, therefore, the A, B, C & D footswitches will
not perform any function until you create Setlists and add Tone Presets into the Setlists. Please see the
POD Farm 2 Basic User Guide for info on creating and managing Setlists (accessible via the POD Farm
2 Help button, or from the POD Farm Online Help site).
• Toe Switch - As listed in the table above, the Toe Switch may be assigned to toggle a Wah model
on/off, or the Bender model on/off in some of the Tone Presets within the POD Farm 2 Source
