11 ULTRA-DI DI100 User Manual
3. Specications
Frequency Response 10 Hz to 93 kHz
Noise Level -110 dBu
THD + N @ 1 kHz / 0 dBu < 0,005 %
Input Impedance > 250 kOhm
Load Impedance > 600 Ohm
Inputs ¼" jack unbal.
In/Link Out XLR unbalanced In
Output XLR balanced Out
Maximum Input level +10/ +30/ +50 dBu
Power supply
Phantom power 18 V DC to 48 V DC
Battery 9 V blockcell 6LR91
Dimensions 150 x 130 x 60 mm
Weight ca. 650 g
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be
made from time to time to existing products without prior notice. Specifications and appearance may differ from those listed or shown.
