①
Antenna
②
AUDIO indicator / IR (infrared detector)
AUDIO indicator: Indicates the audio input level.
IR (infrared detector): Gets the frequency from the receiver
Solid Green: Audio input level is appropriate.
Flashing Red: Audio is muted (i.e., disabled).
For details on setting the mute function, please refer to
"Set Mute key" (page 12).
③
POWER indicator
Indicates the battery level as follows:
Solid Green: Sufficient battery level.
Solid Red: Battery is getting low.
④
Audio input connector (BMP type)
Connect to the supplied lavalier microphone.
⑤
+ or – button
Selects functions or values shown on the display.
⑥
Battery compartment
Accepts two AA batteries (alkaline, nickel metal hydride,
or lithium batteries).
⑦
Power / Mute button
Function Operation
Power ON Press button for one second or longer
Power OFF Press button until it turns off
Mute ON
Short press button
Mute OFF
⑧
SET button
Long press the SET button to enter the displayed menu.
Then, short press the SET button to confirm your option or
long press again to exit without saving.
⑨
LCD display
Display menus, please refer to "LCD Display Operation
Guide" (page 11) for more details.
